Goals

• See how textures can be made available in the pixel shader.
• Understand texture coordinates as part of the geometry.
• Understand the interplay between shaders, multiple render passes and render state.

Welcome to WuggyLand

Open the Tutorial 06 solution in Visual Studio and build and run it. A little interactive scene has been created around the Wuggy rover. Using the W, A, S and D keys, you can now move the rover around the checkerboard-like ground plane.

The entire scene is now contained in one single '.fus' file. All parts of the scene that need to be altered at run-time are identified by unique object names.

But let's look at the things that additionally changed under the hood.

• The Pixel Shader now contains a more sophisticate specular color handling and an additional handling for setting an ambient color.

   uniform float specfactor;
   uniform vec3 speccolor;
   uniform vec3 ambientcolor;
   // ...
   intensitySpec = specfactor * pow(max(0.0, dot(h, nnormal)), shininess);
   gl_FragColor = vec4(ambientcolor + intensityDiff * albedo + intensitySpec * speccolor, 1);

• These new parameters are set from respective entries in the various material components present in the WuggyLand.fus file. This happens in the now extended OnMaterial() method found in Tutorial.cs.

Practice

• Take a look at the new Pixel Shader and try to figure out what the new uniform parameters do. Compare the changes to the Pixel Shader from the previous tutorial. Temporarily comment out parts of the final color calculation to see their individual contribution.
• Set a breakpoint within OnMaterial() and step through the various materials in WuggyLand.fus. Watch the CurrentNode.Name property to identify which material is used on which object and step into the various if and else clauses to see how different materials can be.
• Explain how the emissive component is used here. What would happen if our material handling / Pixel Shader ignored the emissive component?
• Also watch the contents of the material component currently visited. What other information is contained here which is currently NOT handled?

A Hint on Debugging

Since we are using FUSEE's built-in Visitor to traverse the scene graph, the debugger will end up at some awkward code place deep in FUSEE whenever a run-time error occurs during scene traversal in one of our On...() visitor methods.

You can change this behavior in Visual Studio by opening the Debug->Windows->Exception Settings window and check the 'Common Language Runtime Exception' group. Now your application might report Exceptions on startup (e.g. in OpenTK). You can selectively ignore these exceptions as they appear in the Exception Details window. As a result, you should end-up at more specific places with a traceable stack back to your own On...() visitor method causing the exception.

Adding texture information

In WuggyLand.fus, the green parts of the tree models are already prepared to show a very simple leaf-like structure by displaying an image spread over the rounded shapes. If you performed the last point of the Practice block above, you might have noticed that several material components contain a non-null entry in the Diffuse.Texture property.

This string property contains a file name of an image: Leaves.jpg. You can take a look at this image at its location in the Core/Assets Subfolder

Now the material tells us to display this image on the green roundis treetop models. To do this, we have to accomplish two things:

1. Allow the PixelShader to access the pixels inside Leaves.jpg.
2. Tell the PixelShader for each screen pixel (a.k.a "Fragment") it is about to render, which pixel from the texture Leaves.jpg (a.k.a "Texel") it should take as the albedo.

Textures are uniform Shader Parameters

Everything that controlled the process how a vertex shader proceesses coordinates or how a pixel shader calculates the color for a given screen pixel was passed into the shader as a uniform parameter. We have seen single float values, float3 values (used as colors) and float4x4 matrix values.

Since a texture is quite something that influences the way an output color should be calcualted, it is a uniform parameter as well. Because there is much more data behind such a uniform parameter than in the cases before, there are some things that are different compared to 'ordinary' uniform parameters:

• We want to be able to read the contents of a texture image from file.
• We want to be able to upload the texture contents to the GPU memory and 'address' it somehow when needed rather than uploading all the pixels contained in a texture evrey frame.

FUSEE has some functionality we can use to do this. Perform the following steps:

• First of all, add Leaves.jpg to the Fusee.Tutorial06.Core project's Asset folder and set its properties to Content and Copy if newer.

• In the constructor of our Renderer class, get the asset's contents as an instance of the ImageData structure. and use the RenderContext.CreateTexture() method to upload the image to the GPU and get an identifier for it

  ImageData leaves = AssetStorage.Get<ImageData>("Leaves.jpg");
  _leavesTexture = RC.CreateTexture(leaves);
  TextureParam = RC.GetShaderParam(shader, "texture");
  TexMixParam = RC.GetShaderParam(shader, "texmix");

  don't forget to declare the three fields used above at the class level of the Renderer class:

  private IShaderParam TextureParam;
  private IShaderParam TexMixParam;
  private ITexture _leavesTexture;

• To be able to access the texture in the pixel shader, add two uniform variables to PixelShader.frag:

  uniform sampler2D texture;
  uniform float texmix;

  Note the datatype sampler2D (with capital D) in comparison to the datatypes we already used for uniform parameters!

• Now we want to read a color value out of the texture. This can be done using the texture2D() function declared in GLSL. The first parameter of texture2D() is the texture to read from. The second parameter ist a 2D coordinate where both dimensions may contain values from 0 to 1. We will simply pass (0, 0) denoting the lower left pixel of the texture image. In addition, we will use the texmix variable as a means to mix the color value passed in albedo with the color read from the texture. All in all, the resulting pixel shader should look like this:

   #ifdef GL_ES
       precision highp float;
   #endif
   varying vec3 viewpos;
   varying vec3 normal;
   uniform vec3 albedo;
   uniform float shininess;
   uniform float specfactor;
   uniform vec3 speccolor;
   uniform vec3 ambientcolor;
   uniform sampler2D texture;
   uniform float texmix;

   void main()
   {
       vec3 nnormal = normalize(normal);

       // Diffuse
       vec3 lightdir = vec3(0, 0, -1);
       float intensityDiff = dot(nnormal, lightdir);
       vec3 resultingAlbedo = (1.0-texmix) * albedo + texmix * vec3(texture2D(texture, vec2(0, 0)));

       // Specular
       float intensitySpec = 0.0;
       if (intensityDiff > 0.0)
       {
           vec3 viewdir = -viewpos;
           vec3 h = normalize(viewdir+lightdir);
           intensitySpec = specfactor * pow(max(0.0, dot(h, nnormal)), shininess);
       }

       gl_FragColor = vec4(ambientcolor + intensityDiff * resultingAlbedo + intensitySpec * speccolor, 1);
   }

  Note how the resultingAlbedo is now calculated as a mixture between the original albedo and the color at (0, 0) in texture.

• Finally, in OnMaterial, check if there is a texture given (assuming that it's "Leaves.jpg") and set our uniform parameter texture to be the leaves image, as well as texmix to 0 or 1, depending on the presence of a texure in the material.

   if (material.Diffuse.Texture == "Leaves.jpg")
   {
       RC.SetShaderParamTexture(TextureParam, _leafTexture);
       RC.SetShaderParam(TexMixParam, 1.0f);
   }
   else
   {
       RC.SetShaderParam(TexMixParam, 0.0f);
   }

Building and running the solution should result in no changes as the corner we are taking the color information from is nearly the same as the overall diffuse color of the treetop objects' materials.

Practice

• Create a spare copy Leaves.jpg, open the original in an image editing software and assign a color other than green to the lower left corner of the image. Save the image and rebuild the application to see the tree tops appear entirly in that color.
• Just to use other texture coordinates that the original: use the normalized normal's x and y as texture coordinates and try to explan yourself what you see as a result.

Texture Coordinates

Instead of constantly reading the lower left pixel of our image we now we want to read out the correct pixel from the image texture. Typically, the information how a texture is applied to an object is stored with the object's vertices in so called Texture Coordinates. Every vertex contains a two-dimensioal set of texture coordinates (mostly in the range of [0...1]). So the model itself contains this mapping information (often called uv-coordinates, or UVs). The following image shows how a vertex has a set of UV coordinates attached (0.5; 0.5) and how this value identifies a pixel position in the texture.

Once a triangle is rendered, a texture coordinate for every pixel of the triangle can be interpolated from the texture coordinates at the three vertices of the triangle based on the relative position of the pixel to the triangle's vertices. This interpolation happens exactly in the same way we are interpolating normals: As part of the interpolation funcionality that handles every varying parameter passed from the vertex shader to the pixel shader.

This way, any position on the surface has a texture coordinate attached to. Just imagine how every 3D-triangle of your geometry is mapped to a 2D-triangle in UV space.

So all we need to do to get access to the UV coordinates provided with the model and pass it through to the vertex shader. From there put the UV coordinate unchanged into a varying variable thus passing it on to the pixel shader where we can use it already interpolated for the screen-pixel we are currently called for.

In code:

• In the LookupMesh() method where we transform a deserialized MeshComponentinto a renderable Mesh, just add a single line copying the texture- (UV-) coordinates:

   mesh = new Mesh
   {
       Vertices = mc.Vertices,
       Normals = mc.Normals,
       UVs = mc.UVs,
       Triangles = mc.Triangles,
   };

• In the vertex shader, add an attribute vec2 fuUV, a varying vec2 uv and single line copying fuUV´ to uv`. The entire vertex shader should look like this:

   attribute vec3 fuVertex;
   attribute vec3 fuNormal;
   attribute vec2 fuUV;
   uniform mat4 FUSEE_MVP;
   uniform mat4 FUSEE_MV;
   uniform mat4 FUSEE_ITMV;
   varying vec3 normal;
   varying vec3 viewpos;
   varying vec2 uv;

   void main()
   {
       normal = normalize(mat3(FUSEE_ITMV) * fuNormal);
       viewpos = (FUSEE_MV * vec4(fuVertex, 1.0)).xyz;
     	uv = fuUV;
       gl_Position = FUSEE_MVP * vec4(fuVertex, 1.0);
   }

• Finally in the pixel shader, also declare varying vec2 uv and replace vec(0, 0) as the parameter to texture2D() with uv.

Rebuild everything and run it. After all you should be able to explore WuggyLand's flora with its unique foliage:

Effects = Shaders+Passes+Renderstates

To enable advanced visual effects it is often necessary to combine the output of several rendering passes - that is rendering the same geometry more than once with different shaders. Additionally it is often necessary to switch other settings of the rendering pipeline between different passes.

Such combinations of applying several render passes with different shaders and different settings are very often called "Effects" (FX). FUSEE has a support class called ShaderEffect that allows to define effects in a convenient way.

The final stage of this tutorial uses a shader effect instead of a simple shader.

• Visit the [result as web application] (https://cdn.rawgit.com/griestopf/Fusee.Tutorial/b0120f7/Tutorial06Completed/out/Fusee.Tutorial.Web.html) (Ctrl-Click or Long-Press to open in new tab).

• See Tutorial.cs in the Tutorial06 Completed folder for the overall state so far.

Exercise

• Prepare your Renderer to handle geometry with more than one texture.
  • Implement a texture-lookup (using a Dictionary<string, ITexture> object).
• Prepare your Renderer to handle more than one ShaderEffect - e.g. based on object names.
  • In the material visitor lookup the CurrentNode.Name and read the respective effect from a Dictionary<string, ShaderEffect> object wich can be filled in Init().
• Implement a two-pass renderer drawing a black outline.

  • The first pass vertex shader moves transforms each vertex by MVP into clip space and additionally moves it along the x- and y-coordinate of the normal (in clip-space).

  • The first pass pixel shader just assigns black to every pixel

  • The first pass' StateSet should set CullMode = Cull.Clockwise and ZEnable = false

  • The second pass' should use the current vertex and pixel shader.

  • The second pass' StateSet should set CullMode = Cull.Counterclockwise and ZEnable = true Here's an example for such a set:

    Vertex Shader

      attribute vec3 fuVertex;
      attribute vec3 fuNormal;

      varying vec3 normal;

      uniform mat4 FUSEE_MVP;
      uniform mat4 FUSEE_ITMV;

      uniform vec2 linewidth;

      void main()
      {
          normal = mat3(FUSEE_ITMV[0].xyz, FUSEE_ITMV[1].xyz, FUSEE_ITMV[2].xyz) * fuNormal;
          normal = normalize(normal);
          gl_Position = (FUSEE_MVP * vec4(fuVertex, 1.0) ) + vec4(linewidth * normal.xy, 0, 0); // + vec4(0, 0, 0.06, 0);
      }

    Pixel Shader

     #ifdef GL_ES
         precision highp float;
     #endif

     uniform vec4 linecolor;

     void main()
     {
         gl_FragColor = linecolor;
     }

• Note that this outline-renderer only works with geometry with the following properties
  • No overlapping inner parts of geometry is allowed
  • All geometry must have continuous normals at edges. No hard edges allowed. To simulate hard edges, prepare your geometry with bevelled edges with small radii.
• Create some sample geometry matching these requirements and render it during your game.
• Change the second pass to cel-rendering

  • Completely remove the lighting calculation for diffuse and specular parts, instead:

  • Draw, render or download an image of a cartoon-like lit white sphere like the one below. Note that less color fades and more sharp color borders create a more cartoonish look - so you might create better spheres than this!



  • In the pixel shader use this sphere image as a texture to retrieve the overall lighting intensity. Calculate the texture coordinates for this texture from the varying vec3 normal like this: vec2 uv = normal.xy * 0.5 + vec2(0.5, 0.5);

  • Combine the resulting intensity with the albedo from the material.
