FunlearnV2

FunlearnV2 is a from-scratch Kotlin rebuild of the original FunLearn: a two-sided (parent/child) Android learning platform covering tutorials, quizzes, handwriting OCR, a custom coloring engine, and public/private/group chat, built on a dual Firebase backend (Firestore + Realtime Database) with Hilt-driven dependency injection.

Where V1 proved the product concept end-to-end as a solo build, V2 is a deliberate architecture upgrade: DI, a layered repository/ViewModel structure, typed local storage, and role-based navigation replacing V1's single-Activity-per-screen model. The core data layer, auth/role system, chat, and coloring engine are wired and working; several game and quiz screens are still stubs pending the full migration. See Roadmap.

Asset Preview

Static art assets from res/drawable/.

_{Tic-Tac-Toe game board asset}

_{Game background}

_{Chess piece set (GameFourFragment)}

Origin

FunlearnV2 began as a proposed project for Delta Winter of Code (DWoC), an initiative run by Delta, NIT Trichy's software development club, to get students contributing to real, ongoing codebases in the open-source model. Turnout that cycle was light (this was during COVID) so I took the project forward independently and used the opportunity to scope it well beyond the original: Hilt for DI, a backend split between Firestore and Realtime Database by access pattern, typed DataStore in place of raw SQLite, and a role-scoped navigation model built around 4 host Activities instead of 42 flat ones.

1. What Changed from V1

Concern	FunLearn V1	FunlearnV2	Why it matters
Language	Java	Kotlin, full rewrite	Coroutines/Flow-native repository layer
Navigation	42 Activities, `Intent`-extra passing	4 host Activities + Fragments, Navigation Component + Safe Args	Type-safe transitions, shared back-stack handling per role
Dependency management	Manual wiring	Hilt across ViewModels, repositories, Firebase sources (`FirebaseModules.kt`)	Testable, swappable dependencies
Backend	Realtime DB only	Realtime DB for presence/light data + Firestore for structured, queryable collections (chat, classes, quizzes, orders)	Firestore's query model fits chat/classroom/quiz data better than flat key lookups
Local storage	Raw `SQLiteOpenHelper`	Jetpack DataStore (`DataStoreRepository.kt`), coroutine-native typed preferences	Cleaner reads/writes, no manual cursor handling
Account model	No parent/child distinction	Explicit `Roles` enum + separate `ParentActivity`/`ChildActivity` entry points, phone-verified parent accounts	Matches how the product is actually used
Async	RxJava2	Kotlin Coroutines + `kotlinx-coroutines-play-services`, `Flow`-based repositories	Idiomatic Kotlin, sealed `viewmodels/actions` state contracts
Image loading	Glide + Picasso both present	Glide only	One dependency, one caching behavior

2. System Architecture

flowchart TD
    subgraph UI["UI Layer"]
        A1[AuthenticationActivity]
        A2[ParentActivity]
        A3[ChildActivity]
        F[Fragments / Adapters / Widgets]
    end

    subgraph VM["ViewModel Layer"]
        V1[FireStoreViewModel]
        V2[FirebaseDbViewModel]
        V3[BaseViewModel]
    end

    subgraph REPO["Repository Layer"]
        R1[FireStoreRepository]
        R2[FirebaseDbRepository]
        R3[DataStoreRepository]
    end

    subgraph SRC["Data Source Layer"]
        S1[FireStoreSource]
        S2[FirebaseDbSource]
    end

    subgraph DI["Hilt DI — FirebaseModules.kt"]
        M1[FirebaseAuth]
        M2[FirebaseFirestore]
        M3[FirebaseDatabase]
    end

    subgraph BACK["External Services"]
        B1[(Firestore)]
        B2[(Realtime Database)]
        B3[(Firebase Auth)]
        B4[(DataStore — on device)]
    end

    A1 & A2 & A3 --> F
    F --> V1 & V2
    V1 --> R1
    V2 --> R2
    V1 & V2 --> R3
    R1 --> S1
    R2 --> S2
    S1 --> M2
    S2 --> M3
    A1 --> M1
    M1 --> B3
    M2 --> B1
    M3 --> B2
    R3 --> B4

    classDef uiNode fill:#3DDC84,stroke:#2ba86a,color:#000,font-weight:bold
    classDef vmNode fill:#7F52FF,stroke:#5a3adb,color:#fff,font-weight:bold
    classDef repoNode fill:#4285F4,stroke:#2c6fd1,color:#fff
    classDef srcNode fill:#FF7043,stroke:#d84315,color:#fff
    classDef diNode fill:#FFCA28,stroke:#f9a825,color:#000
    classDef fbNode fill:#FFA000,stroke:#e65100,color:#000
    classDef localNode fill:#26A69A,stroke:#00796B,color:#fff

    class A1,A2,A3,F uiNode
    class V1,V2,V3 vmNode
    class R1,R2,R3 repoNode
    class S1,S2 srcNode
    class M1,M2,M3 diNode
    class B1,B2,B3 fbNode
    class B4 localNode

    style UI fill:#e8f5e9,stroke:#3DDC84
    style VM fill:#ede7f6,stroke:#7F52FF
    style REPO fill:#e3f2fd,stroke:#4285F4
    style SRC fill:#fbe9e7,stroke:#FF7043
    style DI fill:#fff8e1,stroke:#FFCA28
    style BACK fill:#fff3e0,stroke:#FFA000

flowchart LR
    subgraph AUTH["AuthenticationActivity"]
        direction TB
        SP[SplashFragment]
        WE[WelcomeFragment]
        GS[GetStartedFragment]
        UT[UserTypeFragment]
        SI[SignInFragment]
        SU[SignUpFragment]
        PV[PhoneVerificationFragment]
        SP --> WE --> GS --> UT
        UT --> SI & SU
        SU --> PV
    end

    subgraph PARENT["ParentActivity"]
        direction TB
        PDB[ParentDashBoardFragment]
        PPV[ParentVerificationFragment]
        PPRO[ProfileFragment]
        PSET[SettingFragment]
        PNOT[NotificationFragment]
        PCHAT[CommonChatFragment]
        PDB --> PPV & PPRO & PSET & PNOT & PCHAT
    end

    subgraph CHILD["ChildActivity"]
        direction TB
        DB[DashBoardFragment]
        FO[FunOptionsFragment]
        LRN[LearnFragment]
        GAMES[GamesFragment]
        CLR["ColouringOne/Two/ThreeFragment"]
        CLS[ClassTypeFragment]
        CHAT[CommonChatFragment]
        PRO[ProfileFragment]
        DB --> FO
        FO --> LRN & GAMES & CLR & CLS & CHAT & PRO
    end

    AUTH -->|"role = PARENT"| PARENT
    AUTH -->|"role = CHILD"| CHILD

    classDef authFrag fill:#EF5350,stroke:#b71c1c,color:#fff
    classDef parentFrag fill:#7F52FF,stroke:#5a3adb,color:#fff
    classDef childFrag fill:#3DDC84,stroke:#2ba86a,color:#000

    class SP,WE,GS,UT,SI,SU,PV authFrag
    class PDB,PPV,PPRO,PSET,PNOT,PCHAT parentFrag
    class DB,FO,LRN,GAMES,CLR,CLS,CHAT,PRO childFrag

    style AUTH fill:#fce4ec,stroke:#EF5350
    style PARENT fill:#ede7f6,stroke:#7F52FF
    style CHILD fill:#e8f5e9,stroke:#3DDC84

Data split: Firestore holds structured content and social data that benefits from querying (Users, Messages, ClassRoom, Questions, Requests, Orders); Realtime Database is reserved for lightweight, frequently-updated key/value data such as online presence. DataStore replaces the old SQLite Level table as the local cache for profile fields, score, and cash so the UI has something to render immediately while Firestore/RTDB catch up.

DI: FirebaseModules.kt provides FirebaseAuth, FirebaseFirestore, and FirebaseDatabase instances via Hilt; repositories and ViewModels (FireStoreViewModel, FirebaseDbViewModel, BaseViewModel) receive them by constructor injection rather than constructing clients themselves.

3. Extended Architecture

This document describes the architectural decisions in FunlearnV2 in more detail than the README overview. It is intended as a reference for contributors and as a record of why the system is structured the way it is.

Background

FunlearnV2 is a from-scratch Kotlin rewrite of FunLearn V1, a Java Android app. V1 proved the feature set end-to-end but accumulated structural debt typical of a first solo build: 42 Activities, no DI, dual image-loading libraries, raw SQLite, and RxJava mixed with ad-hoc threading. V2 is a deliberate structural reset that keeps the same features while replacing the scaffolding.

Layers

UI (Activities / Fragments / Adapters / Widgets)
        ↕  observes / calls
ViewModels (FireStoreViewModel, FirebaseDbViewModel, BaseViewModel)
        ↕  injected via Hilt
Repositories (FireStoreRepository, FirebaseDbRepository, DataStoreRepository)
        ↕  injected via Hilt
Data Sources (FireStoreSource, FirebaseDbSource)  +  Local (DataStore)
        ↕
Firebase (Firestore, Realtime Database, Auth)  +  On-device (DataStore Preferences)

Each layer has a single responsibility. No layer reaches past its immediate neighbour. ViewModels never hold a reference to a Context. Fragments never call Firebase directly.

Entry Points

The app has four Activity-level entry points, all gated by authentication state:

Activity	Role	Hosted Fragments
`AuthenticationActivity`	Unauthenticated launcher	`SignInFragment`, `SignUpFragment`, `UserTypeFragment`
`ParentActivity`	Authenticated, role = PARENT	`ParentDashBoardFragment`, `ParentVerificationFragment`, settings, chat
`ChildActivity`	Authenticated, role = CHILD	`DashBoardFragment`, games, tutorials, coloring, chat, quiz
`BaseActivity`	Shared base	Not navigated to directly — provides common setup

AuthenticationActivity writes a Users document with a Roles enum (PARENT or CHILD) on signup, then routes to the appropriate host Activity. The Roles enum is the single decision point for all role-based routing.

Dependency Injection

classDiagram
    class HiltAndroidApp {
        +FunLearnApplication
    }

    class FirebaseModules {
        +provideFirebaseAuth() FirebaseAuth
        +provideFirestore() FirebaseFirestore
        +provideFirebaseDatabase() FirebaseDatabase
    }

    class FirebaseAuth
    class FirebaseFirestore
    class FirebaseDatabase

    class FireStoreSource {
        -FirebaseAuth auth
        -FirebaseFirestore firestore
    }

    class FirebaseDbSource {
        -FirebaseDatabase database
    }

    class FireStoreRepository {
        -FireStoreSource source
    }

    class FirebaseDbRepository {
        -FirebaseDbSource source
    }

    class DataStoreRepository {
        -ResourceProvider resourceProvider
    }

    class ResourceProvider {
        -DataStore preferences
    }

    class FireStoreViewModel {
        -FireStoreRepository repo
        -DataStoreRepository dataStore
    }

    class FirebaseDbViewModel {
        -FirebaseDbRepository repo
    }

    class BaseViewModel {
        -DataStoreRepository dataStore
    }

    FirebaseModules ..> FirebaseAuth : provides
    FirebaseModules ..> FirebaseFirestore : provides
    FirebaseModules ..> FirebaseDatabase : provides
    FirebaseAuth --> FireStoreSource
    FirebaseFirestore --> FireStoreSource
    FirebaseDatabase --> FirebaseDbSource
    FireStoreSource --> FireStoreRepository
    FirebaseDbSource --> FirebaseDbRepository
    ResourceProvider --> DataStoreRepository
    FireStoreRepository --> FireStoreViewModel
    DataStoreRepository --> FireStoreViewModel
    FirebaseDbRepository --> FirebaseDbViewModel
    DataStoreRepository --> BaseViewModel
    HiltAndroidApp --> FirebaseModules

    style HiltAndroidApp fill:#3DDC84,stroke:#2ba86a,color:#000
    style FirebaseModules fill:#FFCA28,stroke:#f9a825,color:#000
    style FirebaseAuth fill:#FFA000,stroke:#e65100,color:#000
    style FirebaseFirestore fill:#FFA000,stroke:#e65100,color:#000
    style FirebaseDatabase fill:#FFA000,stroke:#e65100,color:#000
    style FireStoreSource fill:#FF7043,stroke:#d84315,color:#fff
    style FirebaseDbSource fill:#FF7043,stroke:#d84315,color:#fff
    style FireStoreRepository fill:#4285F4,stroke:#2c6fd1,color:#fff
    style FirebaseDbRepository fill:#4285F4,stroke:#2c6fd1,color:#fff
    style DataStoreRepository fill:#26A69A,stroke:#00796B,color:#fff
    style ResourceProvider fill:#26A69A,stroke:#00796B,color:#fff
    style FireStoreViewModel fill:#7F52FF,stroke:#5a3adb,color:#fff
    style FirebaseDbViewModel fill:#7F52FF,stroke:#5a3adb,color:#fff
    style BaseViewModel fill:#7F52FF,stroke:#5a3adb,color:#fff

Hilt is the DI framework. FirebaseModules.kt is the only place Firebase client instances are constructed:

@Module
@InstallIn(SingletonComponent::class)
object FirebaseModules {
    @Provides @Singleton fun provideFirebaseAuth(): FirebaseAuth = FirebaseAuth.getInstance()
    @Provides @Singleton fun provideFirestore(): FirebaseFirestore = FirebaseFirestore.getInstance()
    @Provides @Singleton fun provideFirebaseDatabase(): FirebaseDatabase = FirebaseDatabase.getInstance()
}

Repositories receive these instances by constructor injection. ViewModels receive repositories by constructor injection via @HiltViewModel. No component constructs its own dependencies.

Firebase Backend Split

flowchart TD
    DATA([Application Data])
    Q1{Needs structured\nqueries or ordering?}
    Q2{Changes very\nfrequently or low-latency?}
    Q3{User-specific\nlocal cache?}

    FS[(Firestore)]
    RTDB[(Realtime Database)]
    DS[(DataStore on device)]

    FS1[Users profiles and roles]
    FS2[Messages / Comments / Reactions]
    FS3[Requests / GroupDetails]
    FS4[ClassRoom / ClassResource]
    FS5[Questions / QuizResult]
    FS6[Products / Orders]
    FS7[Notifications / Queries / Stats]

    RT1[Online presence indicators]
    RT2[AlphabetImagesAndNames]
    RT3[AlphabetWords / Phrases]
    RT4[Match data / OperatorImages]

    DS1[child and parent profile fields]
    DS2[account credentials cache]
    DS3[score and cash]

    DATA --> Q1
    Q1 -->|Yes| FS
    Q1 -->|No| Q2
    Q2 -->|Yes| RTDB
    Q2 -->|No| Q3
    Q3 -->|Yes| DS
    Q3 -->|No| FS

    FS --> FS1 & FS2 & FS3 & FS4 & FS5 & FS6 & FS7
    RTDB --> RT1 & RT2 & RT3 & RT4
    DS --> DS1 & DS2 & DS3

    classDef dataNode fill:#4285F4,stroke:#2c6fd1,color:#fff,font-weight:bold
    classDef decision fill:#78909C,stroke:#455A64,color:#fff
    classDef firestoreDB fill:#FFA000,stroke:#e65100,color:#000,font-weight:bold
    classDef rtdbDB fill:#FF7043,stroke:#d84315,color:#fff,font-weight:bold
    classDef dsDB fill:#26A69A,stroke:#00796B,color:#fff,font-weight:bold
    classDef fsLeaf fill:#FFE0B2,stroke:#FFA000,color:#000
    classDef rtLeaf fill:#FBE9E7,stroke:#FF7043,color:#000
    classDef dsLeaf fill:#E0F2F1,stroke:#26A69A,color:#000

    class DATA dataNode
    class Q1,Q2,Q3 decision
    class FS firestoreDB
    class RTDB rtdbDB
    class DS dsDB
    class FS1,FS2,FS3,FS4,FS5,FS6,FS7 fsLeaf
    class RT1,RT2,RT3,RT4 rtLeaf
    class DS1,DS2,DS3 dsLeaf

Two Firebase services are used intentionally for different data patterns:

Firestore (structured, queryable)

classDiagram
    class Users {
        +String id
        +String child_name
        +String child_grade
        +String child_profile_image
        +String child_online
        +String child_online_visibility
        +String child_mail
        +String child_dob
        +String child_gender
        +String child_description
        +String parent_name
        +String parent_dob
        +String parent_gender
        +String parent_grade
        +String parent_online
        +String parent_online_visibility
        +String parent_profile_image
        +String parent_mail
        +String account_mail
        +String account_password
        +String mobile_number
        +String address
        +GeoPoint geoPoint
        +Long score
        +Long cash
        +Roles role
    }

    class Messages {
        +String id
        +String from
        +String to
        +String message_content
        +String message_description
        +Timestamp timeStamp
        +Roles role
        +Mode mode
        +MessageTypes message_type
        +ArrayList deleted_by
    }

    class Comments {
        +String id
        +String message_id
        +String from
        +String from_name
        +String comment
        +Timestamp timeStamp
    }

    class Reactions {
        +String message_id
        +String user_id
        +String reaction
    }

    class Requests {
        +String from_id
        +String from_name
        +String to_id
        +String to_name
        +Status status
        +FieldValue timeStamp
    }

    class GroupDetails {
        +String id
        +String group_name
        +String group_description
        +Mode mode
        +ArrayList members
        +FieldValue timeStamp
    }

    class ClassRoom {
        +String id
        +String name
        +String image
        +String meet_url
        +String teacher_name
        +String teacher_id
        +String description
        +String timeStamp
    }

    class ClassResource {
        +String id
        +String class_id
        +String name
        +String image
        +String url
        +String duration
        +String pages
        +String author_name
        +String author_id
        +Resource type
        +FieldValue timeStamp
    }

    class Questions {
        +String resource_id
        +String question
        +String option_A
        +String option_b
        +String option_c
        +String option_D
        +String Answer
    }

    class QuizResult {
        +String quiz_id
        +String user_id
        +String score
        +String attempted
        +String un_attempted
        +String wrong
        +FieldValue timeStamp
    }

    class Products {
        +String id
        +String name
        +String price
        +String description
        +String images
    }

    class Orders {
        +String by_id
        +String by_name
        +String product_id
        +String name
        +String address
        +String description
        +String images
        +OrderStatus status
    }

    class Stats {
        +String user_id
        +ArrayList score
        +ArrayList cash
    }

    class Notifications {
        +String message_description
        +String mode
        +String to_id
        +ArrayList deleted_by
        +FieldValue timeStamp
    }

    class Queries {
        +String message_description
        +String from_id
        +String from_name
        +FieldValue timeStamp
    }

    Users "1" --> "0..*" Messages : sends
    Users "1" --> "0..*" Stats : tracked in
    Users "1" --> "0..*" Orders : places
    Messages "1" --> "0..*" Comments : has
    Messages "1" --> "0..*" Reactions : receives
    Users "1" --> "0..*" Requests : sends/receives
    GroupDetails "1" --> "0..*" Messages : groups
    ClassRoom "1" --> "0..*" ClassResource : contains
    ClassResource "1" --> "0..*" Questions : has when QUIZ
    Users "1" --> "0..*" QuizResult : records
    Products "1" --> "0..*" Orders : referenced by

    style Users fill:#4285F4,stroke:#2c6fd1,color:#fff
    style Messages fill:#7F52FF,stroke:#5a3adb,color:#fff
    style Comments fill:#9575CD,stroke:#6d44bd,color:#fff
    style Reactions fill:#9575CD,stroke:#6d44bd,color:#fff
    style Requests fill:#FF7043,stroke:#d84315,color:#fff
    style GroupDetails fill:#FF7043,stroke:#d84315,color:#fff
    style ClassRoom fill:#3DDC84,stroke:#2ba86a,color:#000
    style ClassResource fill:#3DDC84,stroke:#2ba86a,color:#000
    style Questions fill:#26A69A,stroke:#00796B,color:#fff
    style QuizResult fill:#26A69A,stroke:#00796B,color:#fff
    style Products fill:#FFCA28,stroke:#f9a825,color:#000
    style Orders fill:#FFA000,stroke:#e65100,color:#000
    style Stats fill:#78909C,stroke:#455A64,color:#fff
    style Notifications fill:#78909C,stroke:#455A64,color:#fff
    style Queries fill:#78909C,stroke:#455A64,color:#fff

Used for all data that benefits from a query model — compound queries, ordered collections, secondary-key lookups:

Users — user profiles and role data
Messages, Comments, Reactions — chat
Requests, GroupDetails — group chat management
ClassRoom, Questions, QuizResult — classroom and quiz content
Orders — in-app purchases / rewards

Realtime Database (lightweight, low-latency)

classDiagram
    class FirebaseDbModels {
        +AlphabetImagesAndNames alphabetImagesAndNames
        +ArrayList AlphabetPhrases
        +AlphabetWords alphabetWords
        +ListOfAlphabets listOfAlphabets
        +Match match
        +String OperatorImages
    }

    class AlphabetImagesAndNames {
        +ArrayList Images
        +ArrayList Names
    }

    class AlphabetWords {
        +ArrayList Images
        +ArrayList Words
    }

    class ListOfAlphabets {
        +String Words
    }

    class Match {
        +String Images
        +String Names
    }

    FirebaseDbModels --> AlphabetImagesAndNames
    FirebaseDbModels --> AlphabetWords
    FirebaseDbModels --> ListOfAlphabets
    FirebaseDbModels --> Match

    style FirebaseDbModels fill:#FFA000,stroke:#e65100,color:#000,font-weight:bold
    style AlphabetImagesAndNames fill:#FF7043,stroke:#d84315,color:#fff
    style AlphabetWords fill:#FF7043,stroke:#d84315,color:#fff
    style ListOfAlphabets fill:#FF7043,stroke:#d84315,color:#fff
    style Match fill:#FF7043,stroke:#d84315,color:#fff

Used for data that changes frequently and does not need queries:

Online presence indicators
Counters
Simple key/value flags

The split keeps Firestore costs predictable (fewer reads on frequently-changing data) and keeps the Realtime Database schema flat and fast.

Local State — DataStore

DataStoreRepository wraps a single androidx.datastore.preferences.DataStore instance. Every profile field — both parent and child — plus score and cash is stored as a typed preference. The DataStore is provided by ResourceProvider and injected via Hilt.

This replaces V1's raw SQLiteOpenHelper Level table. The key benefit is coroutine-native access: every field is a Flow<String> that can be observed, or read once with .first() for suspend-style one-shot access.

Read path: UI starts rendering immediately from DataStore. Firestore/RTDB catch up in the background and update the DataStore, which propagates to the UI via Flow.

Write path: User action → ViewModel → Repository → Firestore write + DataStore write. The DataStore write ensures the local cache reflects the latest state immediately.

ViewModel Contracts

%%{init: {'theme': 'base', 'themeVariables': {'primaryColor': '#EDE7F6', 'primaryTextColor': '#1a0050', 'primaryBorderColor': '#7F52FF', 'lineColor': '#37474F', 'secondaryColor': '#E8F5E9', 'secondaryTextColor': '#1b5e20', 'secondaryBorderColor': '#3DDC84', 'tertiaryColor': '#FFF8E1', 'tertiaryTextColor': '#4a3200', 'tertiaryBorderColor': '#FFCA28', 'edgeLabelBackground': '#f5f5f5', 'background': '#ffffff'}}}%%
stateDiagram-v2
    [*] --> Idle

    Idle --> Loading : user action triggers ViewModel call

    Loading --> CreateUser : FireStoreAction.CreateUser
    Loading --> CreateMessage : FireStoreAction.CreateMessage
    Loading --> CreateComment : FireStoreAction.CreateComment
    Loading --> FetchPublicMessages : FireStoreAction.FetchPublicMessages
    Loading --> Error : Firestore exception

    CreateUser --> Idle : Fragment handles result
    CreateMessage --> Idle : Fragment handles result
    CreateComment --> Idle : Fragment handles result
    FetchPublicMessages --> Idle : adapter updated
    Error --> Idle : Fragment shows error UI

ViewModels expose state via sealed action classes in viewmodels/actions/:

FireStoreAction — all Firestore-related states (loading, success variants, error)
FirebaseDbAction — all Realtime Database-related states

Fragments observe a LiveData<FireStoreAction> (or FirebaseDbAction) and handle each state in a when expression. This avoids boolean flags scattered across the Fragment and makes the full set of possible states explicit at compile time.

Navigation

Each host Activity owns a NavHost. Navigation Component handles Fragment back-stack within a host Activity. There are no cross-Activity Fragment transactions.

Safe Args generates typed argument classes from the navigation graph. No Bundle keys are hardcoded as strings anywhere in the Fragment code.

Role-based routing (Parent vs. Child) is done with an explicit startActivity call after authentication, not within the Navigation graph. This keeps the four host Activities as hard boundaries.

Coloring Engine

FloodFill.kt is an object singleton implementing a scanline span-queue flood-fill algorithm. It operates directly on a Bitmap, walking horizontal spans and queuing only the upper and lower boundaries of each span — avoiding the recursive call stack overflow that a naive recursive fill would hit on large bitmaps.

It is shared across three coloring Fragments (ColouringOneFragment, ColouringTwoFragment, ColouringThreeFragment) and the pattern-tracing game (Patterns.kt). PaintView and ColorView are the custom View classes that host the Bitmap and forward touch events to FloodFill.

Chat Architecture

Chat uses a single set of Firestore collections with a Mode enum to distinguish conversation types:

enum class Mode { PRIVATE, PUBLIC, GROUP }

Messages documents carry a mode field. Queries filter by mode. This avoids parallel collection schemas that would drift independently. CommonChatFragment contains shared list and composer logic; PublicChatFragment, PrivateChatFragment, and GroupChatFragment override the parts that differ.

ChatStatusFragment handles real-time presence by writing to Realtime Database on foreground/background transitions.

What V2 Does Not Have Yet

Unit or integration tests. FloodFill and DataStoreRepository are the best starting points — both are side-effect-isolated.
A complete offline-first strategy. DataStore provides an instant-render local cache, but there is no background sync queue for writes made while offline.
Formal data-ownership documentation for every Firestore collection.
Feature-complete stub screens (several game and quiz Fragments are navigation-wired but not fully implemented).

See CHANGELOG.md and the Roadmap section in the README for current status.

4. Tech Stack

Concern	Choice	Notes
Language	Kotlin	Full rewrite of the Java V1 codebase
DI	Hilt (`hilt-android`, `hilt-compiler`)	Wires Firebase clients, repositories, ViewModels
Async	Kotlin Coroutines + `kotlinx-coroutines-play-services`	`Flow`-based repository layer (`DataStoreRepository`)
Backend — structured data	Firestore (`firebase-firestore-ktx`)	Users, chat, classes, quizzes, orders — see §2
Backend — realtime/light data	Firebase Realtime Database (`firebase-database-ktx`)	Presence-style, low-latency key/value data
Auth	Firebase Auth (`firebase-auth-ktx`)	Email/password + phone verification (`PhoneVerificationFragment`)
On-device ML	ML Kit (`ocr`), `play-services-mlkit-text-recognition`	Handwriting recognition, offline
Local persistence	Jetpack DataStore (Preferences)	Typed local cache, replaces V1's SQLite table — see §3.5
Navigation	Android Navigation Component (`navigation-fragment-ktx`, `navigation-ui-ktx`, Safe Args)	Type-safe Fragment transitions inside 4 host Activities
Networking	Retrofit2 + Gson converter	Non-Firebase HTTP needs
Maps/Location	`play-services-maps`, `play-services-location`, Google Places	Location-aware features
Image loading	Glide	Single library (Picasso dropped from V1)
Biometric	`androidx.biometric`	Optional local auth gate
Crash/Analytics	Firebase Crashlytics, Analytics
UI toolkit	Material Components, ConstraintLayout, ViewBinding, RecyclerView	`viewBinding = true` enabled at module level

Full dependency list: app/build.gradle.

5. Feature Notes

User Journeys

%%{init: {'theme': 'base', 'themeVariables': {'fillType0': '#7F52FF', 'fillType1': '#3DDC84', 'fillType2': '#4285F4', 'fillType3': '#FFA000', 'fillType4': '#26A69A', 'fillType5': '#EF5350', 'fillType6': '#FFCA28', 'fillType7': '#FF7043'}}}%%
journey
    title Parent User Journey
    section Onboarding
      Launch app: 5: Parent
      See splash screen: 5: Parent
      Tap Get Started: 4: Parent
      Choose Parent role: 5: Parent
      Sign up with email: 3: Parent
      Verify phone number: 2: Parent
    section Daily Use
      Open parent dashboard: 5: Parent
      Check child profile: 4: Parent
      Monitor quiz scores: 4: Parent
      Open classroom: 4: Parent
      Join class via meet URL: 3: Parent
      Chat with other parents: 4: Parent
    section Settings
      Update profile: 4: Parent
      Toggle online visibility: 5: Parent
      Sign out: 5: Parent

%%{init: {'theme': 'base', 'themeVariables': {'fillType0': '#3DDC84', 'fillType1': '#7F52FF', 'fillType2': '#4285F4', 'fillType3': '#FFA000', 'fillType4': '#26A69A', 'fillType5': '#FF7043', 'fillType6': '#FFCA28', 'fillType7': '#EF5350'}}}%%
journey
    title Child User Journey
    section Onboarding
      Launch app: 5: Child
      Parent creates account: 3: Child
      Child logs in: 4: Child
    section Learning
      Open dashboard: 5: Child
      Choose Fun Options: 5: Child
      Study alphabet lesson: 5: Child
      Practice number writing: 4: Child
      Match alphabet words: 5: Child
    section Games
      Open games menu: 5: Child
      Play Tic-Tac-Toe: 5: Child
      Play chess game: 4: Child
      Earn score and cash: 5: Child
    section Creative
      Open coloring: 5: Child
      Flood-fill a drawing: 5: Child
      Trace patterns: 4: Child
    section Social
      Open public chat: 4: Child
      Send a message: 4: Child
      React to a message: 5: Child
      Join group chat: 3: Child
    section Assessment
      Open classroom: 4: Child
      Watch video resource: 4: Child
      Take quiz: 3: Child
      See quiz result: 5: Child

3.1 Roles: Parent, Child & Authentication

flowchart TD
    LAUNCH([App Launch])
    SPLASH[SplashFragment]
    AUTH_CHECK{Authenticated?}
    WELCOME[WelcomeFragment]
    GETSTARTED[GetStartedFragment]
    USERTYPE[UserTypeFragment]
    SIGNUP[SignUpFragment]
    SIGNIN[SignInFragment]
    FIREBASE_AUTH[(Firebase Auth\nemail/password)]
    ROLE_CHECK{Roles enum\nin Users doc}
    PARENT_VERIFY[ParentVerificationFragment]
    PHONE_VERIFY[PhoneVerificationFragment\nFirebase Phone Auth]
    PARENT_ACT[ParentActivity]
    CHILD_ACT[ChildActivity]

    LAUNCH --> SPLASH --> AUTH_CHECK
    AUTH_CHECK -->|No| WELCOME
    WELCOME --> GETSTARTED --> USERTYPE
    USERTYPE -->|New user| SIGNUP
    USERTYPE -->|Existing user| SIGNIN
    SIGNUP --> FIREBASE_AUTH
    SIGNIN --> FIREBASE_AUTH
    FIREBASE_AUTH --> ROLE_CHECK
    ROLE_CHECK -->|PARENT| PARENT_VERIFY
    PARENT_VERIFY --> PHONE_VERIFY --> PARENT_ACT
    ROLE_CHECK -->|CHILD| CHILD_ACT
    AUTH_CHECK -->|"Yes — PARENT"| PARENT_ACT
    AUTH_CHECK -->|"Yes — CHILD"| CHILD_ACT

    classDef terminal fill:#37474F,stroke:#263238,color:#fff,font-weight:bold
    classDef screen fill:#3DDC84,stroke:#2ba86a,color:#000
    classDef decision fill:#78909C,stroke:#455A64,color:#fff,font-weight:bold
    classDef authScreen fill:#EF5350,stroke:#b71c1c,color:#fff
    classDef firebase fill:#FFA000,stroke:#e65100,color:#000
    classDef activity fill:#7F52FF,stroke:#5a3adb,color:#fff,font-weight:bold

    class LAUNCH terminal
    class SPLASH,WELCOME,GETSTARTED,USERTYPE screen
    class SIGNUP,SIGNIN,PARENT_VERIFY,PHONE_VERIFY authScreen
    class AUTH_CHECK,ROLE_CHECK decision
    class FIREBASE_AUTH firebase
    class PARENT_ACT,CHILD_ACT activity

AuthenticationActivity is the single launcher Activity (see AndroidManifest.xml), fronting SignInFragment / SignUpFragment / UserTypeFragment. Account data is modeled as one Users document (see models/FirestoreModels.kt) carrying both child and parent fields (child_name, child_grade, parent_name, parent_grade, etc.) plus a Roles enum, rather than separate user tables. ParentVerificationFragment and PhoneVerificationFragment gate access before handing off to ParentActivity or ChildActivity.

3.2 Coloring Engine — Flood Fill

flowchart TD
    TOUCH([User taps pixel on PaintView or ColorView])
    READ[Read targetColor at tap point]
    SAME{targetColor == newColor?}
    END([No-op — already filled])
    INIT[Push tap point onto span queue]
    LOOP{Queue empty?}
    POP[Pop next span seed point]
    SCAN_LEFT["Walk left until color changes\nRecord leftmost x"]
    SCAN_RIGHT["Walk right until color changes\nRecord rightmost x"]
    FILL[Fill entire horizontal span with newColor]
    CHECK_ABOVE[Check row above span for targetColor pixels]
    QUEUE_ABOVE[Push contiguous runs above as new seeds]
    CHECK_BELOW[Check row below span]
    QUEUE_BELOW[Push contiguous runs below as new seeds]
    INVALIDATE[Invalidate View — trigger redraw]
    END2([Fill complete])

    TOUCH --> READ --> SAME
    SAME -->|Yes| END
    SAME -->|No| INIT --> LOOP
    LOOP -->|No| POP
    POP --> SCAN_LEFT --> SCAN_RIGHT --> FILL
    FILL --> CHECK_ABOVE --> QUEUE_ABOVE --> CHECK_BELOW --> QUEUE_BELOW --> LOOP
    LOOP -->|Yes| INVALIDATE --> END2

    classDef terminal fill:#37474F,stroke:#263238,color:#fff,font-weight:bold
    classDef decision fill:#78909C,stroke:#455A64,color:#fff
    classDef process fill:#4285F4,stroke:#2c6fd1,color:#fff
    classDef scan fill:#7F52FF,stroke:#5a3adb,color:#fff
    classDef fill fill:#3DDC84,stroke:#2ba86a,color:#000
    classDef done fill:#26A69A,stroke:#00796B,color:#fff

    class TOUCH,END,END2 terminal
    class SAME,LOOP decision
    class READ,INIT,POP,CHECK_ABOVE,CHECK_BELOW,QUEUE_ABOVE,QUEUE_BELOW process
    class SCAN_LEFT,SCAN_RIGHT scan
    class FILL fill
    class INVALIDATE done

The scanline flood-fill from V1 was ported to Kotlin as an object singleton (views/widgets/FloodFill.kt), preserving the same span-queue algorithm to avoid recursive stack overflow on large bitmaps:

object FloodFill {
    fun floodFill(bitmap: Bitmap, point: Point, targetColor: Int, newColor: Int) {
        // walks horizontal spans, queues only span boundaries above/below
        ...
    }
}

It drives PaintView.kt / ColorView.kt and is shared across ColouringOneFragment, ColouringTwoFragment, and ColouringThreeFragment, plus the tracing game in Patterns.kt — the same one-implementation-many-consumers structure as V1's Pattern/ module.

3.3 Chat — Public, Private & Group

flowchart TD
    ENTRY([User opens Chat])
    MODE{Mode?}
    PUB[PublicChatFragment]
    PRIV[PrivateChatFragment]
    GRP[GroupChatFragment]
    COMMON["CommonChatFragment\nshared list and composer"]
    SEND[Send Message]
    MSG[("Messages collection\nmode = PUBLIC / PRIVATE / GROUP")]
    REACT[React or Comment]
    REACT_COL[(Reactions collection)]
    COMMENT_COL[(Comments collection)]
    REQ[Manage Group]
    REQ_COL[("Requests collection\nstatus = PENDING / REJECTED")]
    GD_COL[("GroupDetails collection\nmembers list")]
    STATUS[ChatStatusFragment]
    PRESENCE[(Realtime Database\nonline presence)]

    ENTRY --> MODE
    MODE -->|PUBLIC| PUB
    MODE -->|PRIVATE| PRIV
    MODE -->|GROUP| GRP
    PUB & PRIV & GRP --> COMMON
    COMMON --> SEND & REACT
    SEND --> MSG
    REACT --> REACT_COL & COMMENT_COL
    GRP --> REQ
    REQ --> REQ_COL & GD_COL
    COMMON --> STATUS
    STATUS --> PRESENCE

    classDef terminal fill:#37474F,stroke:#263238,color:#fff
    classDef decision fill:#78909C,stroke:#455A64,color:#fff
    classDef pubFrag fill:#3DDC84,stroke:#2ba86a,color:#000
    classDef privFrag fill:#7F52FF,stroke:#5a3adb,color:#fff
    classDef grpFrag fill:#4285F4,stroke:#2c6fd1,color:#fff
    classDef shared fill:#26A69A,stroke:#00796B,color:#fff,font-weight:bold
    classDef action fill:#FFCA28,stroke:#f9a825,color:#000
    classDef store fill:#FFA000,stroke:#e65100,color:#000
    classDef rtdb fill:#FF7043,stroke:#d84315,color:#fff

    class ENTRY terminal
    class MODE decision
    class PUB pubFrag
    class PRIV privFrag
    class GRP grpFrag
    class COMMON,STATUS shared
    class SEND,REACT,REQ action
    class MSG,REACT_COL,COMMENT_COL,REQ_COL,GD_COL store
    class PRESENCE rtdb

%%{init: {'theme': 'base', 'themeVariables': {'actorBkg': '#7F52FF', 'actorBorder': '#5a3adb', 'actorTextColor': '#ffffff', 'noteBkgColor': '#fff8e1', 'noteTextColor': '#000000', 'noteBorderColor': '#FFCA28', 'activationBkgColor': '#4285F4', 'activationBorderColor': '#2c6fd1', 'signalColor': '#37474F', 'signalTextColor': '#37474F'}}}%%
sequenceDiagram
    participant User
    participant PublicChat as PublicChatFragment
    participant ViewModel as FireStoreViewModel
    participant Repo as FireStoreRepository
    participant Source as FireStoreSource
    participant FS as Firestore

    User->>PublicChat: types message, taps Send

    rect rgb(237, 231, 246)
        Note over PublicChat,Source: Write path — UI to Firestore
        PublicChat->>ViewModel: createMessage(Messages)
        ViewModel->>Repo: createMessage(Messages)
        Repo->>Source: addDocument("Messages", data)
        Source->>FS: collection("Messages").add(data)
        FS-->>Source: DocumentReference
        Source-->>Repo: success
        Repo-->>ViewModel: FireStoreAction.CreateMessage
        ViewModel-->>PublicChat: LiveData update
    end

    rect rgb(227, 242, 253)
        Note over PublicChat,FS: Read path — real-time listener
        PublicChat->>ViewModel: fetchPublicMessages()
        ViewModel->>Repo: getPublicMessages()
        Repo->>Source: query Messages where mode == PUBLIC
        Source->>FS: addSnapshotListener
        FS-->>Source: QuerySnapshot real-time
        Source-->>Repo: List of Messages
        Repo-->>ViewModel: FireStoreAction.FetchPublicMessages
        ViewModel-->>PublicChat: adapter.submitList(messages)
    end

Chat is modeled directly in Firestore via Messages, Comments, Reactions, Requests, and GroupDetails (all in FirestoreModels.kt), with a Mode enum (PRIVATE, PUBLIC, GROUP) distinguishing conversation types on the same collections rather than separate schemas per mode. Fragments split by mode: PublicChatFragment, PrivateChatFragment, GroupChatFragment, CommonChatFragment (shared list/composer logic), CommentFragment, and ChatStatusFragment for presence.

3.4 Quiz, Classroom & Resources

flowchart TD
    CHILD[ChildActivity]
    CLASS_TYPE["ClassTypeFragment\nlist of ClassRoom docs"]
    CLASS_CONTENT["ClassContentFragment\nlist of ClassResource docs"]
    RES_TYPE{Resource.type}
    WEB["WebFragment\nloads meet_url in WebView"]
    PDF["PdfViewFragment\nrenders PDF in viewer"]
    VIDEO["WebFragment\nvideo URL in WebView"]
    QUIZ["QuizFragment\nloads Questions by resource_id"]
    ANSWER["User answers MCQ\noption_A B C D"]
    SCORE["Calculate score\nattempted / wrong / un_attempted"]
    RESULT[(QuizResult written to Firestore)]
    DASH[Score reflected on DashBoardFragment]

    CHILD --> CLASS_TYPE --> CLASS_CONTENT --> RES_TYPE
    RES_TYPE -->|LINK| WEB
    RES_TYPE -->|PDF| PDF
    RES_TYPE -->|VIDEO| VIDEO
    RES_TYPE -->|QUIZ| QUIZ --> ANSWER --> SCORE --> RESULT --> DASH

    classDef activity fill:#7F52FF,stroke:#5a3adb,color:#fff,font-weight:bold
    classDef listFrag fill:#3DDC84,stroke:#2ba86a,color:#000
    classDef decision fill:#78909C,stroke:#455A64,color:#fff
    classDef linkRes fill:#4285F4,stroke:#2c6fd1,color:#fff
    classDef quizRes fill:#FF7043,stroke:#d84315,color:#fff
    classDef quizFlow fill:#FFCA28,stroke:#f9a825,color:#000
    classDef store fill:#FFA000,stroke:#e65100,color:#000
    classDef dashboard fill:#26A69A,stroke:#00796B,color:#fff

    class CHILD activity
    class CLASS_TYPE,CLASS_CONTENT listFrag
    class RES_TYPE decision
    class WEB,PDF,VIDEO linkRes
    class QUIZ quizRes
    class ANSWER,SCORE quizFlow
    class RESULT store
    class DASH dashboard

ClassRoom / ClassResource — a class has a meet_url, teacher_id, and a list of Resource items typed as LINK, PDF, VIDEO, or QUIZ.
Questions — flat MCQ shape (option_A..option_D, Answer) tied to a resource_id.
QuizResult — per-attempt outcome (score, attempted, un_attempted, wrong), mirroring V1's separation of quiz content from quiz outcomes (QuizMaster vs Rank in the original app).
UI: ClassTypeFragment → ClassContentFragment → QuizFragment / PdfViewFragment / WebFragment, depending on Resource type.

3.5 Local State — DataStore

%%{init: {'theme': 'base', 'themeVariables': {'actorBkg': '#4285F4', 'actorBorder': '#2c6fd1', 'actorTextColor': '#ffffff', 'noteBkgColor': '#fff8e1', 'noteTextColor': '#000000', 'noteBorderColor': '#FFCA28', 'activationBkgColor': '#7F52FF', 'activationBorderColor': '#5a3adb', 'sequenceNumberColor': '#ffffff', 'loopTextColor': '#000000', 'labelBoxBkgColor': '#e8f5e9', 'labelBoxBorderColor': '#3DDC84', 'labelTextColor': '#000000', 'signalColor': '#37474F', 'signalTextColor': '#37474F'}}}%%
sequenceDiagram
    participant Fragment
    participant ViewModel as FireStoreViewModel
    participant DSRepo as DataStoreRepository
    participant FSRepo as FireStoreRepository
    participant DS as DataStore on-device
    participant FS as Firestore

    Fragment->>ViewModel: observe LiveData

    rect rgb(232, 245, 233)
        Note over ViewModel,DS: Instant local render
        ViewModel->>DSRepo: read profile fields via first()
        DSRepo->>DS: preferences.data.first()
        DS-->>DSRepo: cached values
        DSRepo-->>ViewModel: profile data
        ViewModel-->>Fragment: render immediately
    end

    rect rgb(227, 242, 253)
        Note over ViewModel,FS: Background Firestore sync
        ViewModel->>FSRepo: fetchUser(uid)
        FSRepo->>FS: get Users document
        FS-->>FSRepo: Users doc snapshot
        FSRepo-->>ViewModel: Users object
        ViewModel->>DSRepo: write updated fields
        DSRepo->>DS: edit preferences
        DS-->>Fragment: Flow emits new values
    end

    Note over Fragment,DS: UI never blank — DataStore renders instantly, Firestore updates propagate via Flow

repository/DataStoreRepository.kt wraps a single androidx.datastore.preferences instance (provided by ResourceProvider) with typed getters/setters for every profile field (child + parent), account credentials cache, score, and cash. Each field is exposed as a Flow<String> internally and read via .first() for one-shot suspend access — replacing V1's raw SQLiteOpenHelper table with a coroutine-friendly, type-checked key-value store.

Enums Reference

classDiagram
    class Roles {
        <<enumeration>>
        TEACHER
        CHILD
        PARENT
        ADMIN
    }

    class Mode {
        <<enumeration>>
        PRIVATE
        PUBLIC
        GROUP
    }

    class Resource {
        <<enumeration>>
        LINK
        PDF
        VIDEO
        QUIZ
    }

    class MessageTypes {
        <<enumeration>>
        TEXT
        PDF
        VIDEO
    }

    class Status {
        <<enumeration>>
        PENDING
        REJECTED
    }

    class OrderStatus {
        <<enumeration>>
        PENDING
        DELIVERED
    }

    class Grade {
        <<enumeration>>
        PREKG
        LKG
        UKG
    }

    class ParentGrade {
        <<enumeration>>
        SCHOOL
        COLLEGE
        NOCOMMENTS
    }

    class OnlineVisibility {
        <<enumeration>>
        ONLINE
        OFFLINE
    }

    class Gender {
        <<enumeration>>
        MALE
        FEMALE
        NOTOSAY
    }

    style Roles fill:#EF5350,stroke:#b71c1c,color:#fff
    style Mode fill:#7F52FF,stroke:#5a3adb,color:#fff
    style Resource fill:#3DDC84,stroke:#2ba86a,color:#000
    style MessageTypes fill:#4285F4,stroke:#2c6fd1,color:#fff
    style Status fill:#FF7043,stroke:#d84315,color:#fff
    style OrderStatus fill:#FFA000,stroke:#e65100,color:#000
    style Grade fill:#26A69A,stroke:#00796B,color:#fff
    style ParentGrade fill:#26A69A,stroke:#00796B,color:#fff
    style OnlineVisibility fill:#78909C,stroke:#455A64,color:#fff
    style Gender fill:#FFCA28,stroke:#f9a825,color:#000

6. Module Reference

app/src/main/java/com/example/funlearnv2/
├── FirebaseSource/     FirebaseDbSource, FireStoreSource, FirebaseModules, Collections — data-source layer (§2)
├── models/             DataModel, FirebaseDbModels, FirestoreModels, chatModel, Result — data/DTO layer (§3.3, §3.4)
├── repository/         DataStoreRepository (§3.5), FireStoreRepository, FirebaseDbRepository
├── viewmodels/         BaseViewModel, FireStoreViewModel, FirebaseDbViewModel
│   └── actions/         FireStoreAction, FirebaseDbAction — sealed action/state contracts for ViewModels
├── utils/              CallUtil, ContextUtil, DateUtil, DialogUtil, DimensionUtil,
│                        FileUtil, FileSaveUtil, GlideUtil, HideKeyboardUtil, InputTextUtil,
│                        ProgressBarUtil, QueryUtil, SnackbarUtil, ViewGroupUtil, ViewUtil
│   ├── constants/        Constant, ButtonStatus, FunType, OperatorTypes
│   └── resourceProvider/ ResourceProvider — DataStore + resource access wrapper
├── views/
│   ├── activities/      AuthenticationActivity, BaseActivity, ParentActivity, ChildActivity (§2, §3.1)
│   ├── fragments/        45 Fragments across:
│   │                      - Onboarding: SplashFragment, WelcomeFragment, GetStartedFragment
│   │                      - Auth: SignInFragment, SignUpFragment, UserTypeFragment,
│   │                               PhoneVerificationFragment, ParentVerificationFragment
│   │                      - Dashboard: DashBoardFragment, ParentDashBoardFragment, FunOptionsFragment
│   │                      - Learn: LearnFragment, AlphabetListFragment, AlphabetCountFragment,
│   │                               AlphabetWordsFragment, AlphabetMatchFragment, AlphabetWriteFragment,
│   │                               NumberInfoFragment, NumberCountFragment, NumberOperationFragment,
│   │                               NumberWriteFragment, TutorialFragment
│   │                      - Games: GamesFragment, GameOnePlayFragment, GameTwoFragment,
│   │                               GameThreeFragment, GameFourFragment (chess)
│   │                      - Coloring: ColouringOneFragment, ColouringTwoFragment, ColouringThreeFragment
│   │                      - Chat: CommonChatFragment, PublicChatFragment, PrivateChatFragment,
│   │                               GroupChatFragment, CommentFragment, ChatStatusFragment
│   │                      - Classroom/Quiz: ClassTypeFragment, ClassContentFragment, QuizFragment,
│   │                                        PdfViewFragment, WebFragment, ListFilesFragment
│   │                      - Profile/Settings: ProfileFragment, SettingFragment, NotificationFragment
│   │                      Several of the above are navigation-wired stubs pending full V1 migration
│   ├── adapters/         16 adapters (15 RecyclerView + 1 ViewPager2) — one per list-backed screen
│   │                      ItemAlphabetAdapter, ItemAlphabetWordAdapter, ItemChessAdapter,
│   │                      ItemCommentAdapter, ItemDeadChessAdapter, ItemGameOneAdapter,
│   │                      ItemMatchAdapter, ItemNumbersInfoAdapter, ItemOperatorAdapter,
│   │                      ItemPatternAdapter, ItemPublicChatMessageAdapter, ItemSearchAdapter,
│   │                      ItemTemplateAdapter, ItemWordAdapter, ItemWordExampleAdapter,
│   │                      chatViewPagerAdapter
│   └── widgets/          FloodFill, PaintView, ColorView, Patterns, GameImages (§3.2)
└── FunLearnApplication.kt   @HiltAndroidApp entry point

7. Roadmap

Finish stub screens (a subset of Fragments across games/quiz/settings are wired for navigation but not yet feature-complete) and confirm full V1 to V2 parity, then retire the legacy Java module.
Extend DataStoreRepository into a full offline-first cache layer, with Firestore as the sync source of truth across devices.
Formalize the FirebaseDbSource / FireStoreSource boundary into a documented data-ownership map as more collections are added.
Add unit tests, starting with FloodFill and DataStoreRepository — both are side-effect-isolated and straightforward to unit test; no test suite exists yet.
Continue extracting game logic into ViewModels (in progress for the larger game Fragments) to keep game rules testable independent of the view layer.
Replace the Asset Preview section with real screenshots and screen recordings of the running app.

8. Getting Started

git clone https://github.com/PRADEEPERIYASAMY/FunLearnV2.git
cd FunLearnV2

Create a Firebase project; enable Firestore, Realtime Database, Authentication (email/password + phone), Crashlytics, and ML Kit Text Recognition.
Download google-services.json into app/ (a placeholder already exists in this repo; replace it with your own project's file).
Open the repository root folder in Android Studio (Gradle + com.google.gms.google-services + Hilt + Navigation Safe Args plugins) and let Gradle sync.
- The project uses JitPack (https://jitpack.io) as a Maven repository for some dependencies (see build.gradle root). Android Studio adds this automatically; no manual step needed.
Build:

./gradlew build

For a full walkthrough of Firebase service configuration, see Firebase Setup. For build environment details, see Local Development Guide.

9. Firebase Setup

This guide walks through configuring Firebase for a local development build of FunlearnV2. The app depends on five Firebase services: Authentication, Firestore, Realtime Database, Crashlytics, and ML Kit Text Recognition.

Prerequisites

A Google account
Android Studio (Arctic Fox or later recommended)
The repository cloned locally

Step 1 — Create a Firebase Project

Go to console.firebase.google.com and click Add project.
Name the project (e.g. FunlearnV2-Dev). Analytics can be enabled or disabled — it does not affect core functionality.
Wait for the project to be provisioned.

Step 2 — Register the Android App

In the Firebase Console, click the Android icon to add an Android app.
Enter the package name: com.example.funlearnv2
App nickname is optional. SHA-1 is required for phone authentication (see Step 5).
Click Register app.
Download google-services.json and place it at app/google-services.json in the repo, replacing the placeholder file already there.

The placeholder google-services.json committed to this repository contains dummy values. It will not connect to any real Firebase project. Replace it with your own.

Step 3 — Enable Authentication

In the Firebase Console, go to Authentication > Sign-in method.
Enable Email/Password.
Enable Phone (required for PhoneVerificationFragment and ParentVerificationFragment).
For phone authentication in debug builds, go to Authentication > Sign-in method > Phone and add a test phone number and verification code under Phone numbers for testing.

SHA-1 for Phone Auth

Phone authentication requires the app's signing certificate SHA-1 to be registered in the Firebase project.

For the debug keystore:

keytool -list -v -keystore ~/.android/debug.keystore -alias androiddebugkey -storepass android -keypass android

On Windows:

keytool -list -v -keystore %USERPROFILE%\.android\debug.keystore -alias androiddebugkey -storepass android -keypass android

Copy the SHA-1 fingerprint and add it under Project settings > Your apps > SHA certificate fingerprints.

Step 4 — Set Up Firestore

Go to Firestore Database and click Create database.
Choose Start in test mode for local development (allows open reads/writes for 30 days — tighten rules before any production use).
Select a region close to you.

Firestore Collections

The app expects the following top-level collections:

Collection	Used by	Key fields
`Users`	Auth, profile, roles	`uid`, `role` (`PARENT`/`CHILD`), `child_name`, `child_grade`, `parent_name`, `parent_grade`
`Messages`	Chat	`mode` (`PRIVATE`/`PUBLIC`/`GROUP`), `sender_id`, `receiver_id`, `text`, `timestamp`
`Comments`	Chat	`message_id`, `sender_id`, `text`
`Reactions`	Chat	`message_id`, `user_id`, `type`
`Requests`	Group chat	`sender_id`, `receiver_id`, `status`
`GroupDetails`	Group chat	`group_id`, `name`, `members`
`ClassRoom`	Classroom	`teacher_id`, `meet_url`, `resources`
`Questions`	Quiz	`resource_id`, `question`, `option_A`..`option_D`, `Answer`
`QuizResult`	Quiz	`user_id`, `resource_id`, `score`, `attempted`, `wrong`
`Orders`	Shop/rewards	`user_id`, `item_id`, `status`

Collections are created automatically when the app first writes to them. You do not need to create them manually.

Step 5 — Set Up Realtime Database

Go to Realtime Database and click Create database.
Choose Start in test mode for development.
Select a region.

Realtime Database is used for lightweight, frequently-updated data: online presence indicators and counters. The data structure is created on first write from the app.

Step 6 — Enable ML Kit Text Recognition

ML Kit Text Recognition runs on-device and does not require a separate Firebase configuration step. The dependency play-services-mlkit-text-recognition downloads the model on first use.

If you want the model bundled with the APK (to avoid a first-run download), add the following to your AndroidManifest.xml:

<meta-data
    android:name="com.google.mlkit.vision.DEPENDENCIES"
    android:value="ocr" />

This is already present in the app manifest.

Step 7 — Enable Crashlytics

In the Firebase Console, go to Crashlytics and click Enable Crashlytics.
No additional configuration is needed — the google-services.json and firebase-crashlytics plugin handle the rest.
To generate a test crash, call throw RuntimeException("Test Crash") from any Activity and confirm it appears in the Crashlytics dashboard.

Step 8 — Sync and Build

Open the repo root in Android Studio.
Let Gradle sync complete (it will download all dependencies declared in app/build.gradle).
Build and run:

./gradlew build

Or run directly from Android Studio using the Run button.

Firestore Security Rules (Production)

Before deploying to production, replace the permissive test rules with real rules. A starting point:

rules_version = '2';
service cloud.firestore {
  match /databases/{database}/documents {

    // Users can only read and write their own document
    match /Users/{userId} {
      allow read, write: if request.auth != null && request.auth.uid == userId;
    }

    // Messages: authenticated users only
    match /Messages/{messageId} {
      allow read, write: if request.auth != null;
    }

    // Add rules per collection as the app matures
  }
}

Start strict and open up. The test-mode default (allow all) is not safe for production.

Realtime Database Security Rules (Production)

{
  "rules": {
    ".read": "auth != null",
    ".write": "auth != null"
  }
}

This restricts all reads and writes to authenticated users. Tighten per node as needed.

Troubleshooting

google-services.json errors at sync time Make sure the file is placed at app/google-services.json, not the repo root. The file must match the package name com.example.funlearnv2.

Phone auth — SMS not received Add the device's test phone number in Firebase Console under Authentication > Sign-in method > Phone > Test phone numbers.

ML Kit model not found Clean the build (./gradlew clean) and rebuild. On first launch, the model is downloaded; a network connection is needed.

Crashlytics not reporting crashes Crashlytics is disabled during debug builds by default. To force-enable it for testing, add FirebaseCrashlytics.getInstance().setCrashlyticsCollectionEnabled(true) in FunLearnApplication.kt.

10. Local Development Guide

Everything you need to set up a local development environment for FunlearnV2 beyond what git clone and Android Studio handle automatically.

Prerequisites

Tool	Version	Notes
Android Studio	Arctic Fox (2020.3.1) or later	Hedgehog or later recommended
JDK	8 (Java 1.8)	Set in `compileOptions` and `kotlinOptions`
Android SDK	API 30 (compile + target)	API 23 minimum for device/emulator
Kotlin	Check `build.gradle` (root) for `kotlin_version`	kapt used for annotation processing
Gradle	Wrapper included — use `./gradlew`	Do not use a system Gradle installation

Initial Setup

git clone https://github.com/PRADEEPERIYASAMY/FunLearnV2.git
cd FunLearnV2

Then follow docs/FIREBASE_SETUP.md to configure Firebase before your first build.

Building

# Debug build
./gradlew assembleDebug

# Release build (APK unsigned, requires signing config for distribution)
./gradlew assembleRelease

# Full build with tests
./gradlew build

On Windows, use gradlew.bat instead of ./gradlew, or run via Android Studio's built-in Gradle panel.

Running on a Device or Emulator

Use Android Studio's Run button, or:

./gradlew installDebug

The minimum supported API level is 23 (Android 6.0 Marshmallow). For emulators, an API 23+ AVD is required.

Plugins and Build Configuration

flowchart LR
    SRC["Kotlin Source\n.kt files"]
    KAPT[kotlin-kapt\nAnnotation Processing]
    HILT_GEN["Hilt Generated Code\nDagger components"]
    GLIDE_GEN["Glide Generated\nGlideApp"]
    NAV_ARGS["Safe Args Generated\nDirections and Args classes"]
    KOTLIN[kotlin-android\nKotlin compilation]
    ANDROID["com.android.application\nDex and resource merge"]
    GMS["com.google.gms.google-services\nInjects Firebase config"]
    CRASHLYTICS["com.google.firebase.crashlytics\nInjects build ID"]
    HILT_PLUGIN["dagger.hilt.android.plugin\nbytecode transform"]
    APK[APK\ndebug / release]

    SRC --> KAPT
    KAPT --> HILT_GEN & GLIDE_GEN & NAV_ARGS
    SRC --> KOTLIN
    HILT_GEN & GLIDE_GEN & NAV_ARGS --> KOTLIN
    KOTLIN --> ANDROID --> GMS --> CRASHLYTICS --> HILT_PLUGIN --> APK

    classDef source fill:#37474F,stroke:#263238,color:#fff,font-weight:bold
    classDef kapt fill:#FFCA28,stroke:#f9a825,color:#000,font-weight:bold
    classDef generated fill:#FFF9C4,stroke:#FFCA28,color:#000
    classDef compile fill:#7F52FF,stroke:#5a3adb,color:#fff
    classDef android fill:#3DDC84,stroke:#2ba86a,color:#000
    classDef gms fill:#FFA000,stroke:#e65100,color:#000
    classDef crash fill:#EF5350,stroke:#b71c1c,color:#fff
    classDef hilt fill:#4285F4,stroke:#2c6fd1,color:#fff
    classDef artifact fill:#26A69A,stroke:#00796B,color:#fff,font-weight:bold

    class SRC source
    class KAPT kapt
    class HILT_GEN,GLIDE_GEN,NAV_ARGS generated
    class KOTLIN compile
    class ANDROID android
    class GMS gms
    class CRASHLYTICS crash
    class HILT_PLUGIN hilt
    class APK artifact

All diagrams reflect the codebase as of the current main branch. Update this file when models, navigation graphs, or the architecture changes.

Made with ❤️ by Pradeep Periyasamy

The project uses the following Gradle plugins — all are applied in app/build.gradle:

Plugin	Purpose
`com.android.application`	Android app module
`kotlin-android`	Kotlin support
`kotlin-kapt`	Annotation processing (Hilt, Glide compiler)
`com.google.gms.google-services`	Firebase configuration
`dagger.hilt.android.plugin`	Hilt DI
`androidx.navigation.safeargs.kotlin`	Navigation Safe Args
`com.google.firebase.crashlytics`	Crashlytics build integration

Plugin versions are declared in the root build.gradle.

Key Build Flags

Flag	Value	Notes
`minSdkVersion`	23	Android 6.0
`targetSdkVersion`	30	Android 11
`compileSdkVersion`	30
`viewBinding`	true	All view access goes through generated binding classes
`multiDexEnabled`	true	Required due to method count exceeding 64K

Project Structure

FunLearnV2/
├── app/
│   ├── build.gradle              # App-level dependencies and build config
│   ├── google-services.json      # Firebase config (placeholder — replace with your own)
│   ├── proguard-rules.pro        # ProGuard rules for release builds
│   └── src/
│       └── main/
│           ├── AndroidManifest.xml
│           ├── java/com/example/funlearnv2/
│           │   ├── FirebaseSource/    # Data-source layer
│           │   ├── models/            # Data models and DTOs
│           │   ├── repository/        # Repository layer
│           │   ├── viewmodels/        # ViewModels and action contracts
│           │   ├── utils/             # Extension helpers and utilities
│           │   ├── views/             # Activities, Fragments, adapters, widgets
│           │   └── FunLearnApplication.kt
│           └── res/
├── build.gradle                  # Root build file (plugin versions, classpath)
├── gradle.properties             # Gradle and project-wide properties
├── settings.gradle               # Module inclusion
└── docs/                         # Extended documentation

Code Conventions

Language: Kotlin throughout. No new Java files.
View access: ViewBinding only. No findViewById.
Dependency injection: Hilt. Do not construct Firebase clients, repositories, or ViewModels manually.
Async: Kotlin Coroutines and Flow. No RxJava, no raw threads, no AsyncTask.
Image loading: Glide only. Picasso was removed from V1 and is not re-introduced.
Navigation: Navigation Component + Safe Args for all Fragment transitions within a host Activity. No Intent extras for passing typed data between Fragments.

Running Lint

./gradlew lint

The lint report is generated at app/build/reports/lint-results-debug.html.

Running Tests

# Unit tests
./gradlew test

# Instrumented tests (requires a connected device or running emulator)
./gradlew connectedAndroidTest

Note: as of the current state of the project, test coverage is minimal. FloodFill and DataStoreRepository are the best candidates for new unit tests since both are side-effect-isolated.

Common Issues

Gradle sync fails with google-services.json error The placeholder google-services.json will not cause a sync failure on its own, but building or running will fail without valid Firebase credentials. See FIREBASE_SETUP.md.

kapt errors during build Ensure kapt { correctErrorTypes true } is present in app/build.gradle (it is). If kapt errors persist after a code change, try ./gradlew clean before rebuilding.

Navigation Safe Args not generating Clean and rebuild: ./gradlew clean assembleDebug. If the generated Directions classes are missing, confirm the androidx.navigation.safeargs.kotlin plugin is applied in app/build.gradle.

Hilt injection failures at runtime All Activities and Fragments using Hilt must extend ComponentActivity / Fragment (not the legacy support versions) and the Application class must be annotated with @HiltAndroidApp. Both are already configured in this project.

MultiDex issues on API 21 and above multiDexEnabled true is set and androidx.multidex:multidex is included. The FunLearnApplication class inherits from MultiDexApplication indirectly via Hilt's generated Application. No additional configuration is needed.

IDE Tips

Enable auto-import for Kotlin in Android Studio to avoid manual import management.
Use Layout Inspector (View > Tool Windows > Layout Inspector) to inspect the Fragment/View hierarchy at runtime.
The Navigation graph is at app/src/main/res/navigation/ — open it in the Navigation Editor for a visual overview of Fragment transitions per host Activity.

11. Contributing & Community

Contributions, bug reports, and feature requests are welcome.

Read CONTRIBUTING.md before opening a pull request.
Review the Code of Conduct — all interactions in this project follow it.
Report security issues privately via SECURITY.md.
Need help? See SUPPORT.md.
Use the issue templates when filing bugs or feature requests.

This project is primarily a solo build. If you want to contribute, open an issue first to discuss scope before writing code.

Licensed under MIT.

Made with ❤️ by Pradeep Periyasamy

Name		Name	Last commit message	Last commit date
Latest commit History 9 Commits
.github		.github
.idea		.idea
.vscode		.vscode
app		app
gradle/wrapper		gradle/wrapper
.gitignore		.gitignore
ACKNOWLEDGMENTS.md		ACKNOWLEDGMENTS.md
CHANGELOG.md		CHANGELOG.md
CODE_OF_CONDUCT.md		CODE_OF_CONDUCT.md
CONTRIBUTING.md		CONTRIBUTING.md
LICENSE		LICENSE
README.md		README.md
SECURITY.md		SECURITY.md
SUPPORT.md		SUPPORT.md
build.gradle		build.gradle
gradle.properties		gradle.properties
gradlew		gradlew
gradlew.bat		gradlew.bat
settings.gradle		settings.gradle

Folders and files

Latest commit

History

Repository files navigation

FunlearnV2

Table of Contents

Asset Preview

Origin

1. What Changed from V1

2. System Architecture

3. Extended Architecture

Background

Layers

Entry Points

Dependency Injection

Firebase Backend Split

Firestore (structured, queryable)

Realtime Database (lightweight, low-latency)

Local State — DataStore

ViewModel Contracts

Navigation

Coloring Engine

Chat Architecture

What V2 Does Not Have Yet

4. Tech Stack

5. Feature Notes

User Journeys

3.1 Roles: Parent, Child & Authentication

3.2 Coloring Engine — Flood Fill

3.3 Chat — Public, Private & Group

3.4 Quiz, Classroom & Resources

3.5 Local State — DataStore

Enums Reference

6. Module Reference

7. Roadmap

8. Getting Started

9. Firebase Setup

Prerequisites

Step 1 — Create a Firebase Project

Step 2 — Register the Android App

Step 3 — Enable Authentication

SHA-1 for Phone Auth

Step 4 — Set Up Firestore

Firestore Collections

Step 5 — Set Up Realtime Database

Step 6 — Enable ML Kit Text Recognition

Step 7 — Enable Crashlytics

Step 8 — Sync and Build

Firestore Security Rules (Production)

Realtime Database Security Rules (Production)

Troubleshooting

10. Local Development Guide

Prerequisites

Initial Setup

Building

Running on a Device or Emulator

Plugins and Build Configuration

Key Build Flags

Project Structure

Code Conventions

Running Lint

Running Tests

Common Issues

IDE Tips

11. Contributing & Community

About

Resources

Code of conduct

Contributing

Security policy

Stars

Watchers

Forks

Releases

Packages

Used by

Contributors

Languages
