Generative AI Full Course Lecture 5 Hard vs Soft Masks and Differential Diffusion

Generative AI Full Course - Lecture 5: Hard vs Soft Masks & Differential Diffusion

Full tutorial link > https://www.youtube.com/watch?v=DJcgVASlg38

Choose where an image changes in ComfyUI. Lecture 5 of this 14-lecture course covers masks, inpainting, outpainting, SAM3 selection, face edits, transparent PNGs and editable layers on Windows.

🔗 Links:

Windows AI requirements guide: [ https://www.patreon.com/posts/111553210 ]

📦 Full course resource repository: [ https://github.com/FurkanGozukara/Generative-AI-Tools-And-Tecniques-2026-2027-Fall ]

▶️ Lecture 1 — Windows setup and your first image: [ https://youtu.be/KgUhPAOjagI ]

📺 Full course playlist: [ https://www.youtube.com/playlist?list=PLUMEJUep1hiI ]

SECourses Discord: [ https://discord.com/invite/software-engineering-courses-secourses-772774097734074388 ]

🎯 You will learn how to paint and inspect masks, repair an invented signature, extend a scene, select objects with words, edit a face through Crop-and-Stitch, and place a transparent lantern over a background.

🧩 Main topics include Differential Diffusion, denoise, exact outside-region compositing, alpha polarity, Color Transfer and Qwen Image Layered.

Use the chapters to revisit each operation, setting group and comparison.

⏱️ Chapters:

00:00:00 Choose where an image changes

00:00:59 Update the existing ComfyUI installation

00:01:30 Activate the correct environment

00:01:43 Update source, packages and restart

00:02:26 Save the installation state before a custom node

00:03:30 Install Crop-and-Stitch from the Registry

00:04:48 Separate instruction editing from exact preservation

00:05:14 Sampling masks versus pixel composites

00:05:55 Paint and inspect a hard selection

00:06:22 Brush hardness, size and erasing

00:07:05 Mask pen versus image paint pen

00:07:19 Save and preview the actual mask

00:07:44 Compare brush hardness and selection edges

00:08:16 Alt-drag brush shortcut

00:08:42 Select a garment by colour

00:08:55 Tolerance and unwanted selections

00:09:51 Paint Bucket versus Color Select

00:10:59 Inspect the actual Week 3 signature

00:11:26 Cover every signature stroke

00:12:15 Build the masked latent path

00:12:29 VAE Encode and Set Latent Noise Mask

00:13:13 Fill prompt, fixed seed and denoise

00:14:24 Run and inspect the hard-mask repair

00:14:47 Inspect the repair boundary

00:15:27 Grow and blur the selection with Differential Diffusion

00:15:55 Blur radius, sigma and mask conversion

00:16:28 Connect Differential Diffusion

00:17:38 Compare the patch and restore outside pixels

00:18:06 Aligned before-and-after slider

00:18:19 Remaining fragments at denoise 0.75

00:18:33 Repeat both repairs at denoise 1.0

00:19:16 Composite onto the original pixels

00:19:39 Check outside the complete soft edge

00:20:22 Read a grey mask as a start-time map

00:20:56 Grey values and denoising strength

00:21:26 Run and inspect the ramp result

00:22:09 Extend a canvas with a matched editing graph

00:22:22 Padding, feathering and alignment

00:23:04 Run and inspect the extended scene

00:23:48 Preserve the original region

00:24:17 Load the segmentation model and its encoder

00:24:43 SAM3.1 download and loader wiring

00:25:37 Short phrases and token context

00:25:50 Select objects and inspect individual masks

00:26:19 Select the jacket by text

00:26:53 Individual windows and count limits

00:28:00 Detection threshold and refinement

00:28:30 Prepare a large photograph for a local edit

00:28:59 Glasses instruction and face mask

00:29:43 Inspect the whole-frame editing route

00:30:26 Run and inspect the whole-frame edit

00:31:10 Build and run the crop-and-stitch path

00:32:00 Crop context and output size

00:32:49 Mask expansion versus blend width

00:33:03 Connect and run Inpaint Stitch

00:34:03 Compare detail, timing and outside pixels

00:34:31 Actual timings and run conditions

00:34:45 Restore pixels outside the face edit

00:36:01 Generate a lantern with real transparency

00:36:57 Inspect light and dark backgrounds

00:37:31 Reload the saved transparent PNG

00:37:45 Trace opacity and inverted masks through the nodes

00:38:03 Invert the loader mask for compositing

00:38:48 Join Image with Alpha conventions

00:39:29 Place the transparent asset on a background

00:39:57 Offsets, source size and mask alignment

00:40:45 Generated alpha versus segmentation

00:41:55 Match colour and inspect alpha interpretation

00:42:20 Color Transfer method and strength

00:43:02 Straight versus premultiplied alpha

00:44:07 Prepare the separate layer-decomposition workflow

00:44:36 Layered model files and folders

00:45:43 Working resolution and layer count

00:46:37 Inspect and recombine the ordered RGBA layers

00:47:07 Composite the layers in order

00:47:50 Reconstruction versus original source

00:48:29 Move the lantern and inspect the revealed background

00:48:47 Inspect the newly revealed background

00:49:16 Check old shadows and reflections

00:49:45 Save and reopen the editable result

00:50:21 Choose the selection method and save a reusable result

00:51:06 Lesson files and model instructions

00:51:24 Practice and Lecture 6 preview

Follow Lecture 1 for Windows setup. The lesson files include source images, masks, workflows, saved results and model links.

💬 For help, check the pinned comment, join Discord or leave a comment. Support SECourses on Patreon for more guides and resources.

#ComfyUI #GenerativeAI #Inpainting

Video Transcription

• 00:00:00 Greetings everyone. Today I am going to show you  how to choose exactly where an image changes in

• 00:00:05 ComfyUI. We will paint masks, select objects with  words, and edit small regions. Look at the lower

• 00:00:13 right corner of our watercolor from Lecture 3.  The model invented a little signature. We will

• 00:00:19 repair that mark while keeping the surrounding  painting, then inspect the boundary closely.

• 00:00:29 We will also extend an image, work  on a face inside a large photograph,

• 00:00:33 generate a transparent asset, and separate a  product scene into editable layers. Each job

• 00:00:39 uses the selection differently. Check out  the tutorial description for the chapters

• 00:00:49 and downloadable lesson files. We will work in  our familiar ComfyUI installation, then build

• 00:00:55 and compare the image editing graphs. Before  we begin, I am updating our existing ComfyUI

• 00:01:03 installation. Lecture 2 explains this routine in  detail. We will use the same application folder

• 00:01:08 and virtual environment, and keep our model  folders. I am opening the application folder,

• 00:01:17 then typing CMD in its address bar. This opens  Command Prompt in the correct directory. Check

• 00:01:23 that the displayed path points to your ComfyUI  installation. First I activate the virtual

• 00:01:31 environment. The environment name appears at the  prompt. Now I can update this installation without

• 00:01:38 sending the package command to a different Python  on the computer. I am running git pull with the

• 00:01:45 fast forward only option. It downloads the current  source changes. If Git reports a local conflict,

• 00:01:51 resolve that specific conflict before continuing  with the package update. Next I install the

• 00:01:57 requirements with this environment's Python. Keep  the installation output visible until the command

• 00:02:03 finishes. Then restart ComfyUI so the running  application loads the updated files and packages.

• 00:02:11 The application is back. Our existing models  remain available through their configured folders.

• 00:02:17 We will introduce the additional model files  when we reach segmentation and image layers,

• 00:02:23 instead of installing unrelated packs. Our  first custom node pack will help us edit a

• 00:02:29 small region of a large image. Before installing  it, we will save the current installation state,

• 00:02:35 so we have the working versions available for  recovery. This Manager build uses the Extensions

• 00:02:42 panel for installing packs. Its snapshot service  is available through the local application. I am

• 00:02:48 opening Command Prompt to save a snapshot before  changing the installed nodes. The command calls

• 00:03:02 the Manager snapshot service on this ComfyUI  address. It saves the installed versions in

• 00:03:07 the user's Manager folder. We will inspect that  saved file before going back to the browser.

• 00:03:14 A snapshot records application and pack versions.  Keep your workflows and model files as well. Those

• 00:03:21 are separate assets, and you will need them when  restoring a complete working setup on another

• 00:03:26 computer. Back in ComfyUI, I am opening Extensions  and searching for Crop and Stitch. Choose the pack

• 00:03:35 by lquesada. Its description explains the 2  operations: extract a region around a mask,

• 00:03:41 then place the edited result back. Look at  the pack name and version before installing.

• 00:03:47 Several packs contain similar words. We  want ComfyUI Inpaint Crop and Stitch,

• 00:03:52 which provides the paired crop and stitch nodes  used in this lecture. I am clicking Install for

• 00:03:58 that Registry entry. Wait for installation  to finish, then restart ComfyUI. Restarting

• 00:04:04 loads the new Python nodes; refreshing the browser  alone cannot load code into an old server process.

• 00:04:19 After the restart, I press R to refresh the node  definitions. Now I am opening the node search

• 00:04:25 and looking for Inpaint Crop. The scissors symbol  helps identify this pack's displayed node names.

• 00:04:32 The pair is Inpaint Crop and Inpaint Stitch. Use  the current nodes from the installed pack. The

• 00:04:38 supplied workflows keep their class and version  information, which helps distinguish them from

• 00:04:44 older examples with similar display names. Here  is the instruction edit from Lecture 4 beside its

• 00:04:51 original. We asked for a local change, but an  edit model can also alter texture or lighting

• 00:04:57 elsewhere. Let us inspect those surrounding  details together. Pause and predict: if the

• 00:05:03 model can find a jacket from our instruction, why  would we still use a mask? Think about a job where

• 00:05:09 the other objects and background must remain  unchanged. A mask gives us an explicit spatial

• 00:05:16 selection. We can use that selection to guide  generation, choose a crop, or composite pixels.

• 00:05:22 Those are separate operations even when they use  the same painted shape. The noise mask belongs to

• 00:05:28 the sampling process. An explicit image composite  happens after decoding. When you need unchanged

• 00:05:34 outside pixels, keep the original destination and  place only the accepted patch over it. We will use

• 00:05:41 the visible mask preview throughout this lecture.  A white region is selected for these editing and

• 00:05:47 source-compositing nodes. Black is excluded, while  grey supplies a partial value to the receiving

• 00:05:53 operation. I am loading our workshop image. The  man, the red car and the building give us several

• 00:06:00 clear targets. First we will paint a selection  by hand, then compare it with selections made

• 00:06:06 from colour and words. Select the Load Image  node and open its mask editor. The base image

• 00:06:13 is the picture underneath. The mask layer stores  the selection separately, so painting the mask

• 00:06:18 does not directly recolour the photograph. I am  choosing the mask pen and setting hardness to 1.

• 00:06:25 Watch the edge as I paint over part of the jacket.  A fully hard brush makes a sharp transition

• 00:06:31 between the selected and unselected area. Brush  thickness controls the size of the painted stroke.

• 00:06:41 Use a larger brush for the interior and a  smaller one near a boundary. I am keeping

• 00:06:46 the stroke inside the jacket while you watch its  outline. If a stroke crosses the boundary, use

• 00:06:54 the eraser to remove that part of the selection.  The eraser changes the mask. The base photograph

• 00:07:00 remains available underneath while we correct  the painted region. The paint pen is different:

• 00:07:06 it edits the image's colour layer. For this  selection exercise we keep the mask pen active.

• 00:07:12 Check the tool and active layer before drawing,  especially after switching between editing tasks.

• 00:07:18 I am saving the mask back to the Load Image node  and connecting its mask output to Mask to Image.

• 00:07:25 This preview shows the actual single-channel  selection that the graph will receive. Notice

• 00:07:31 that we have saved both the original image and  the mask. The source remains available for another

• 00:07:37 attempt or for the final pixel composite. We  are not replacing the original file with the

• 00:07:42 painted preview. Now I am reopening the editor and  changing hardness to 0.2. I will paint a nearby

• 00:07:49 stroke so we can compare its edge with the hard  stroke we just made on the same image. The softer

• 00:08:02 stroke includes a wider grey transition. Look at  that transition in the mask preview. Its effect

• 00:08:08 depends on the next node: a compositor blends  pixels, while Differential Diffusion uses it

• 00:08:14 during sampling. You can adjust brush size and  hardness with the editor's brush shortcut. Hold

• 00:08:20 Alt and drag with the right mouse button. Move  horizontally for size and vertically for hardness

• 00:08:27 while watching the displayed controls. Use the  shortcut when it helps you stay over the area

• 00:08:33 you are painting. For an exact comparison, enter  the value in the control and inspect the preview

• 00:08:39 before running the downstream graph. Painting is  useful for a specific outline, but this jacket

• 00:08:46 also has a distinctive colour. I am clearing the  practice strokes and choosing Color Select so we

• 00:08:52 can select pixels that share that colour. I am  clicking the jacket and adjusting the tolerance

• 00:08:58 while watching the mask. Too narrow a selection  misses shaded fabric. Too broad a selection can

• 00:09:04 include similarly coloured material elsewhere  in the image. Look beyond the main jacket area.

• 00:09:11 Colour selection compares colour, so it can  pick an unrelated object with similar values.

• 00:09:16 Remove those unwanted regions with the mask  eraser before using the selection for an edit.

• 00:09:51 Paint Bucket follows a connected region  around the clicked location. Color

• 00:09:55 Select can find matching colours  across the image. Choose between

• 00:09:59 them by inspecting whether you want 1  connected patch or all matching pixels.

• 00:10:46 The mask preview is the final check. Follow  the shoulders, sleeves and jacket opening.

• 00:10:51 Save the useful selection, then return to the  graph so we can apply the same spatial ideas

• 00:10:56 to the watercolor repair. Here is the original  watercolor from the 0.8 LoRA example in Lecture

• 00:11:04 3. I am keeping that source unchanged. The repair  will be a separate output, with its own mask and

• 00:11:10 workflow. Let us enlarge the lower right corner.  The unwanted handwritten mark sits over the

• 00:11:17 water texture. We want to replace the mark with  plausible water while keeping the lighthouse,

• 00:11:22 rocks and surrounding brushwork intact. I am  opening the mask editor and painting over the

• 00:11:29 entire mark, including its thin edges. Leave  some nearby water visible around the selection,

• 00:11:35 because that context helps the new  patch match the existing painting.

• 00:11:47 Save the hard mask and inspect it through Mask  to Image. Make sure every unwanted stroke lies

• 00:11:53 inside the white area. A missed fragment outside  the selection can survive even when the generated

• 00:11:59 patch looks convincing. We will compare  2 versions with the same source, prompt,

• 00:12:05 seed and sampler settings. The first uses the  hard mask. The second grows and softens the

• 00:12:11 selection and applies Differential Diffusion  to the model. For this seam experiment we use

• 00:12:17 the Z-Image-Turbo model from Lecture 1. I am  opening its matched loader and decoder graph.

• 00:12:23 The watercolor is the source image, rather than  a new text-only starting latent. First connect

• 00:12:29 the loaded image to VAE Encode. The matching  VAE converts the source pixels into the latent

• 00:12:35 representation used by this model. Keep the image  decoder connected to that same matched VAE. Now I

• 00:12:42 am adding Set Latent Noise Mask. Connect  the encoded latent to its samples input,

• 00:12:47 then connect our painted mask to its mask input.  This attaches the spatial selection to the

• 00:12:53 original latent. The masked latent goes into the  sampler's latent image input. The model and text

• 00:13:04 conditioning still connect as usual. Follow those  paths together: the prompt describes the fill,

• 00:13:09 and the mask chooses its spatial region. Our  prompt describes clear watercolor water continuing

• 00:13:16 the nearby colour and brush texture. We remove  the unwanted mark through the selected region,

• 00:13:23 rather than asking the model to redesign the  lighthouse or the whole composition. I am

• 00:13:29 keeping the seed fixed and using the same sampler  settings for both versions. Denoise controls the

• 00:13:36 amount of regeneration within this path. We will  read the selected values beside the results when

• 00:13:41 comparing them. The original source latent still  carries image information. As denoise increases,

• 00:13:48 more of the selected detail can be replaced.  Choose the value by inspecting whether the

• 00:13:53 unwanted mark remains and whether the new water  fits. After sampling, VAE Decode turns the latent

• 00:14:01 into pixels. I am saving this decoded result  separately. Before we accept it, we will inspect

• 00:14:06 the patch and compare the surrounding picture  against the original. I am also keeping the

• 00:14:12 original image connected to the final composite's  destination. The edited image will be its source.

• 00:14:18 We will connect the accepted mask after choosing  the version we want to keep. The hard-mask graph

• 00:14:25 is ready. I am starting the run now. Watch  the sampler progress and completion, then we

• 00:14:30 will enlarge the lower right patch to inspect  the replaced mark and the edge of the repair.

• 00:14:46 Here is the decoded result. Start with the place  where the signature was, then follow the boundary

• 00:14:52 around that patch. Compare the water's colour,  texture and stroke direction with the surrounding

• 00:14:58 original image. A hard boundary can reveal a  change even when the unwanted object is gone.

• 00:15:05 Look for a sudden shift in colour or texture. We  will compare this version with a graded selection

• 00:15:11 under the same generation settings. Keep the  hard-mask result visible in the comparison. We

• 00:15:17 will preserve this output and its recipe, then  change only the mask treatment and model patch

• 00:15:24 needed for the next version of the experiment.  Back in the graph, I am adding Grow Mask after

• 00:15:30 the painted selection. A small positive expansion  covers the edge around the unwanted mark. Negative

• 00:15:36 expansion would shrink the selection instead,  which could expose missed fragments. I am

• 00:15:42 setting the expansion to 8 pixels for this source.  Watch the mask preview as the white region grows.

• 00:15:49 The useful distance depends on the image and the  object boundary, so judge it in pixels here. Next

• 00:15:55 convert the mask to an image and pass it through  Blur. This creates a graded transition around the

• 00:16:01 expanded region. Then Image to Mask converts the  red channel back into a mask for the latent node.

• 00:16:14 The blur radius controls the neighbourhood, and  sigma controls how the blur is distributed. We

• 00:16:20 keep the settings visible beside the preview. The  goal is a smooth boundary while still covering the

• 00:16:26 full unwanted mark. Now I am placing Differential  Diffusion between the model loader and the

• 00:16:32 sampler. It is a model patch in this graph. The  graded mask still enters Set Latent Noise Mask

• 00:16:38 through the latent path. Follow both connections  at once. The mask supplies spatial values,

• 00:16:58 and Differential Diffusion interprets them during  the denoising schedule. White regions participate

• 00:17:03 earlier; darker grey regions join later as the  schedule progresses. We keep the original source,

• 00:17:10 prompt, seed and sampler values from the hard-mask  run. The change we are testing is the grown and

• 00:17:17 blurred selection with Differential Diffusion. I  am starting that second run now. After decoding,

• 00:17:25 the new result is saved under its own name.  Keeping both outputs makes the comparison

• 00:17:31 reversible. We can choose the better  patch without losing the original mask,

• 00:17:35 image or first generation. I am placing the  original and repaired images side by side with

• 00:17:41 clear labels. First compare the full painting,  then concentrate on the lower right water. The

• 00:17:47 repair should serve the composition as well as  the enlarged patch. Now let us compare the 2

• 00:17:54 repair versions at the same scale. Follow the edge  of each selection and inspect the water texture.

• 00:18:01 Choose the version whose patch blends more  naturally with the surrounding brushwork. The

• 00:18:06 aligned slider lets us inspect the same location  before and after. I am moving it slowly across

• 00:18:12 the repaired mark. Watch a fixed feature near the  boundary so small shifts remain easy to see. The

• 00:18:19 enlarged comparison reveals small dark fragments  in both initial repairs. The mask covers the

• 00:18:25 writing, but this denoise setting still preserves  too much of its structure. I am keeping those

• 00:18:31 results as evidence. I am raising denoise to 1  in the hard-mask version. The source, prompt,

• 00:18:38 seed and remaining sampler settings stay the  same. This gives the selected area more freedom

• 00:18:43 to replace the remaining fragments. The graded  version uses the same higher denoise value. Its

• 00:18:57 mask treatment and Differential Diffusion remain  the comparison variables. After both files are

• 00:19:03 saved, we can judge the texture and boundary  at matching scale. Once we choose the patch,

• 00:19:18 connect that edited image to the composite source  and the original to its destination. The accepted

• 00:19:24 mask selects the patch. Outside that selection,  the destination supplies the original pixels. I

• 00:19:39 am saving the final composite and reopening  it. Now compare the outside region against

• 00:19:44 the source. A 0 difference outside the accepted  mask means those saved pixels are identical to

• 00:19:50 the original painting. The grey boundary is part  of the accepted blending region. Measure outside

• 00:19:56 the complete mask support, including that soft  edge. Otherwise a deliberately blended edge can

• 00:20:03 be mistaken for an unwanted change outside the  repair. Return to the full composition before

• 00:20:09 finishing. The lighthouse and rocks give us  context, while the repaired corner should

• 00:20:14 read as continuous water. Keep the original, both  masks and the chosen repair in the lesson folder.

• 00:20:22 Let us make the grey values easier to understand  with a ramp. The mask moves gradually from black

• 00:20:27 on one side to white on the other. We will  use it on the same masked latent path. I am

• 00:20:41 previewing the ramp before connecting it to the  sampler. Black, grey and white now occupy large

• 00:20:47 visible regions. That makes the change across the  schedule easier to inspect than a narrow feather

• 00:20:53 around a small patch. With Differential Diffusion  connected, the white end participates through more

• 00:21:00 of the denoising process. Darker values join  later. The grey mask therefore controls when

• 00:21:06 different spatial regions begin changing  during this particular sampler schedule.

• 00:21:12 The strength control blends the patch's behaviour.  We will keep it at 1 for this demonstration so

• 00:21:18 the thresholded schedule is clear. The result  still depends on the selected model, source and

• 00:21:24 denoise settings. I am starting the ramp run with  a visible change in the prompt. Watch the output

• 00:21:31 from the black end through the middle to the white  end. Compare how much source structure remains

• 00:21:37 across that transition. Here is the result beside  the ramp. Move your attention along the gradient

• 00:21:46 and compare corresponding image regions. The  relationship is easier to read when the source,

• 00:21:51 mask and output are aligned at the same scale.  This is useful when the centre of a repair needs

• 00:21:59 a strong change while its boundary should stay  closer to the source. Shape the mask for the edit,

• 00:22:05 then inspect whether the generated transition  actually fits. Now we will turn spatial selection

• 00:22:11 outward. I am loading the workshop scene  into Image Pad for Outpaint. Padding creates

• 00:22:16 a larger canvas and a mask for the area that  did not exist in the original picture. I am

• 00:22:23 adding space to the left side and keeping the  other sides unchanged. Look at both outputs:

• 00:22:28 the padded image provides the context, and the  mask identifies the new area we want the model to

• 00:22:34 fill. Feathering gives the boundary a transition  region. We also keep the final dimensions aligned

• 00:22:41 to the grid used by our Qwen 2.1 workflow. Padding  increments and the model's required alignment are

• 00:22:49 separate settings. The padded image goes into the  matched Qwen instruction graph. Our prompt asks

• 00:22:55 it to continue the street, building and lighting  into the new area. It uses the existing scene as

• 00:23:01 the reference for that extension. I am starting  the outpaint. When it finishes, inspect the old

• 00:23:07 and new sides together. Follow the pavement,  roofline and wall texture across the boundary,

• 00:23:14 because an extension needs continuity as well as  attractive new content. Here is the wider canvas.

• 00:23:36 I am bringing the boundary into view at a readable  scale. Compare the direction of lines, the size of

• 00:23:42 repeated features, and the brightness on both  sides of the original edge. To preserve the

• 00:23:48 original region exactly, use the padded original  as the composite destination and the generated

• 00:23:54 extension as its source. The pad mask selects  the new region and its chosen transition edge.

• 00:24:02 I am saving that composite and comparing the  original region again. Choose a modest extension

• 00:24:07 when a wider one loses the scene's perspective.  You can grow the canvas in stages while keeping

• 00:24:14 each accepted source available. Manual masks  work well for a small repair. For an entire car,

• 00:24:21 jacket or window, we can ask a segmentation  model for the selection. We will use the native

• 00:24:26 SAM3 detection node in ComfyUI. The model download  belongs in the checkpoints folder. This checkpoint

• 00:24:33 includes the model and its text encoder, so we  load it with Load Checkpoint. It uses a different

• 00:24:39 component set from our image generation  graph. I am opening the model's download

• 00:24:45 page and selecting the checkpoint file. Keep its  complete filename. Once the download finishes,

• 00:24:51 place it in the checkpoints folder that  this ComfyUI installation actually searches.

• 00:25:05 After refreshing the model list, select that  checkpoint in Load Checkpoint. Connect its

• 00:25:10 model output to SAM Detect, and its clip output  to the text encoding node. Our workshop image

• 00:25:16 supplies the image input. The selection prompt  describes an object to find. It does not ask

• 00:25:28 the image model to redraw that object. The  detection result is a mask we can inspect,

• 00:25:33 edit or pass into the other workflows. This  installed text encoder uses a 32-token context.

• 00:25:40 Keep the phrase short and specific. We will  use the red car, the jacket, and every window,

• 00:25:46 instead of a long paragraph describing the  whole scene. First I am entering the red

• 00:25:51 car and running the detection graph. The mask  output goes through Mask to Image so we can

• 00:25:57 inspect it. Compare its silhouette with the car  before using it in an edit. Look at the wheels,

• 00:26:07 roof and glass boundaries. A detected mask is a  starting selection. If part of the surrounding

• 00:26:12 pavement is included, or a required edge is  missing, correct the mask before compositing the

• 00:26:18 image. Now I am changing only the phrase to the  jacket. The same image and model stay connected.

• 00:26:24 Watch how the selected region moves from the car  to the man's clothing without us painting a new

• 00:26:30 outline. We can use this mask as the starting  point for a clothing edit. Inspect the collar

• 00:26:43 and sleeves, then choose the amount of growth and  feathering for the receiving workflow. Selection

• 00:26:49 and generation remain separate steps. For windows,  I am enabling individual masks. This returns

• 00:26:56 separate detected instances instead of combining  every selected window into 1 mask. We can inspect

• 00:27:03 the batch 1 image at a time before choosing a  particular window. This installed encoder keeps

• 00:27:09 1 detection per phrase by default. I am adding  a colon and an upper count to the window phrase.

• 00:27:15 That allows several matching windows to pass into  the individual mask batch. The count is a limit,

• 00:27:22 not a request to invent extra windows. We keep the  phrase concise and run detection again. Compare

• 00:27:28 each returned mask with the visible building  and keep their order clear in the saved files.

• 00:28:00 Threshold controls which detections are  accepted. A higher value keeps stronger matches;

• 00:28:06 lowering it can admit more candidates. Change it  only while inspecting whether the extra selection

• 00:28:12 belongs to the object you actually want. The  refinement setting works on the mask boundary

• 00:28:18 after detection. Inspect thin frames and gaps  at a closer view. Keep a useful mask separately

• 00:28:24 so a later parameter change does not replace  the selection you already accepted. Now let

• 00:28:30 us edit a face inside a larger photograph.  This source is a photograph by Toan Van,

• 00:28:36 provided with its credit in the lesson files.  We will keep the original and save the edited

• 00:28:41 versions separately. I am setting the image's  long edge to 4096 pixels. The same saved source

• 00:28:49 feeds both comparisons. Look at the face area  relative to the whole canvas before we decide

• 00:28:54 how much of it to process. Our instruction  will add round eyeglasses while keeping the

• 00:29:02 man's expression and the rest of the scene. We  will first send the whole picture through Qwen,

• 00:29:08 then edit a crop around the face with the  same instruction. I am painting the face

• 00:29:14 selection and leaving surrounding hair and skin  as context. The mask defines where we want the

• 00:29:20 final change. We will use that same region when  checking the outside pixels after stitching.

• 00:29:43 In the whole-frame graph, the entire photograph  enters Text Encode Qwen-Image 2.1. Its resolution

• 00:29:50 control sets the reference pixel budget while  preserving the image's aspect ratio on the

• 00:29:55 required grid. At this budget, the face occupies  only part of the resized reference. The rest of

• 00:30:02 the pixels describe clothing and background. Keep  that distribution in mind when we compare the face

• 00:30:08 with a separately enlarged crop. I am entering the  glasses instruction and keeping the seed fixed.

• 00:30:15 The sampler, model and text remain visible in  the graph. We will preserve these values for

• 00:30:21 the crop comparison so the changed processing  region is clear. I am starting the whole-frame

• 00:30:27 run. We will read its actual execution time  from the application when it finishes. Keep

• 00:30:32 the first model-loading work separate from  the repeated sampling work when interpreting

• 00:30:38 that time. Here is the whole-frame edit. Inspect  the glasses, the eyes and the surrounding hair,

• 00:30:46 then look at the jacket and background. A local  instruction can still produce other changes when

• 00:30:51 the complete picture is regenerated. I am saving  this version before changing the graph. It is the

• 00:30:58 whole-frame comparison, with its original  prompt and settings. Next we will give the

• 00:31:03 face more of the model's working image area.  Add Inpaint Crop after the loaded photograph

• 00:31:13 and face mask. The crop node returns the  extracted image, its mask, and a stitcher

• 00:31:18 object. That object carries the information  needed to place the edited crop back correctly.

• 00:31:39 Connect the cropped image to the Qwen reference  input. Keep the crop mask visible in a preview.

• 00:31:45 The model now receives the local region and its  surrounding context instead of the full photograph

• 00:31:51 at the same working budget. Context controls how  much surrounding image the crop includes. Too

• 00:32:04 little can hide the hairstyle or lighting cues  needed by the edit. Too much spends the working

• 00:32:10 area on background and makes the face smaller  again. I am increasing the context around the

• 00:32:16 face until the crop includes its immediate  surroundings. Watch the cropped preview as

• 00:32:22 the region changes. Keep both the target and  the useful nearby details within this view.

• 00:32:35 The output size controls the working dimensions  of the crop. We choose a size that suits the Qwen

• 00:32:41 graph and keep its required alignment. The final  photograph keeps its original canvas size after

• 00:32:47 stitching. Mask expansion and blend width serve  different roles. Expansion changes the selected

• 00:32:54 area. The blend controls the transition when the  edited crop returns to the original. Inspect both

• 00:33:00 the crop preview and the final edge. Now connect  the crop's stitcher output to Inpaint Stitch,

• 00:33:07 and the decoded edited crop to its image  input. The node uses the saved placement

• 00:33:12 information to return that local result  to the full photograph. I am keeping the

• 00:33:18 same glasses instruction and seed as the  whole-frame run. The crop changes what the

• 00:33:23 model sees at this working size, so compare  the resulting face as well as the time taken.

• 00:33:29 The graph is connected, and I am starting the crop  run. After the model finishes, follow the edited

• 00:33:35 image into the stitch node. The saved output  should have the full photograph's dimensions

• 00:33:41 and the local edit in place. Here is the stitched  result. Inspect the glasses and eye area first,

• 00:33:54 then follow the blend around the face. Look for  changes in skin tone, hair detail or sharpness

• 00:34:00 that make the inserted region stand out. Let us  place both edited faces beside the original at the

• 00:34:07 same scale. The labels identify the whole-frame  route and the crop route. Compare the rims,

• 00:34:12 pupils, hairline and expression before choosing  the result to keep. I am enlarging the same region

• 00:34:19 to 400%. This makes small differences visible.  Judge the shapes and consistency with the source;

• 00:34:26 sharper invented texture is not automatically a  more faithful face. The displayed times come from

• 00:34:33 these actual runs. Keep the hardware, working  size and model-loading conditions beside the

• 00:34:38 comparison. A crop can change both the amount  of processing and the detail available to the

• 00:34:44 model. Now compare the saved outside region  with the original photograph. If the stitch

• 00:34:50 has changed pixels beyond the accepted blend  mask, use the original as the destination of

• 00:34:56 an explicit final composite to restore them. I  am saving that final version and checking the

• 00:35:12 difference again. The accepted edit includes the  chosen blend edge. Outside its complete support,

• 00:35:19 the original supplies the pixels that we want to  preserve exactly. Return to the full photograph

• 00:35:38 before finishing. A convincing close view should  also fit the original composition and lighting.

• 00:35:44 Keep both comparison outputs, the face mask  and the final workflow so you can repeat the

• 00:35:50 same operation. Now we will create an object that  can be placed over another image. Qwen-Image 2.1

• 00:36:06 supports a native transparent output through  its matched image decoder. We will generate a

• 00:36:11 lantern and inspect its actual alpha channel. I  am opening the transparent-output workflow with

• 00:36:19 the same Qwen 2.1 component set. The prompt asks  for an isolated brass lantern with a transparent

• 00:36:25 background. The saved image needs to retain all 4  channels. The red, green and blue channels store

• 00:36:32 colour. Alpha stores opacity. A fully opaque  point has alpha 1, while a transparent point

• 00:36:38 has alpha 0. Intermediate values represent  a partially transparent edge or material.

• 00:36:44 I am starting the lantern generation. When it  finishes, we will view the asset over both light

• 00:36:50 and dark backgrounds. This makes an unwanted solid  background or a coloured edge easier to spot. Here

• 00:36:57 is the lantern over the light background. Inspect  the handle, its thin metal parts and the glass.

• 00:37:03 Now switch to the dark background and inspect  the same boundary, keeping the asset at the

• 00:37:09 same scale. A checkerboard drawn into the colour  image would stay visible on both backgrounds. Real

• 00:37:17 alpha lets the new background show through the  transparent pixels. We will inspect the alpha

• 00:37:23 preview as well as the composed appearance. I am  saving the lantern as a PNG, then loading that

• 00:37:33 saved file back into the graph. This checks  the file we will actually reuse. A preview

• 00:37:38 on the screen is useful only if the saved asset  retains its transparency. Connect the reloaded

• 00:37:46 image's mask output to Mask to Image. Notice the  convention used by Load Image: transparent areas

• 00:37:52 are white in this mask. It is the inverse  of the alpha opacity stored in the PNG.

• 00:38:03 For Image Composite Masked, white selects  the source. We therefore add Invert Mask

• 00:38:08 before using this transparency mask to place  the lantern. The lantern becomes selected,

• 00:38:14 and the empty background becomes excluded  from the source. Follow the 2 paths together.

• 00:38:26 The image output carries the lantern colours, and  the inverted mask carries its opacity selection.

• 00:38:32 Those inputs meet at the compositor, where the  destination supplies the background image. Join

• 00:38:49 Image with Alpha uses the matching inverted-mask  convention. Connecting the loader's mask there

• 00:38:54 rebuilds the original opacity. Read each node's  convention instead of assuming every input called

• 00:39:00 mask or alpha uses the same polarity. The direct  alpha channel of a 4-channel image is opacity. If

• 00:39:15 we extract it with Image to Mask, opaque areas  are white. Keep that route distinct from the

• 00:39:21 transparency mask returned by the file loader. I  am loading the background image into the composite

• 00:39:32 destination and the lantern into its source.  The opacity selection goes into the mask input.

• 00:39:38 We can now position this saved object without  asking a model to regenerate the background.

• 00:39:56 The horizontal and vertical offsets  choose where the source begins on

• 00:40:01 the destination canvas. I am moving  the lantern into place while keeping

• 00:40:05 its dimensions visible. Inspect the contact  point and the surrounding space as it moves.

• 00:40:15 Source resizing changes the object scale. Keep  the image and opacity mask aligned when you resize

• 00:40:20 them. A mismatched mask can cut into the lantern  or leave a displaced edge around its silhouette.

• 00:40:45 Now inspect the final boundary over this  background. The generated glass and metal

• 00:40:49 may need different opacity detail. A segmentation  mask selects visible regions; the generated alpha

• 00:40:56 can include partial transparency inside the  asset itself. We can compare the lantern's

• 00:41:02 generated alpha with a segmentation selection  of the same object. Look especially at the

• 00:41:08 handle opening and glass. Choose the selection  that preserves the appearance needed by this

• 00:41:14 particular composite. I am saving the composed  result while retaining the separate lantern

• 00:41:31 PNG. Keeping the asset separate lets us move or  colour-match it later. The background remains

• 00:41:37 the original destination outside the lantern's  accepted opacity region. The lantern also needs

• 00:41:57 to fit the background's colour and lighting. I  am adding Color Transfer to the source branch,

• 00:42:02 with the background as its reference. The mask  and placement stay available while we compare

• 00:42:08 the colour change. The method controls how colour  statistics are matched, and strength blends the

• 00:42:25 correction. Start with a moderate strength  and inspect the brass, glass and shadows. A

• 00:42:31 stronger numerical setting is useful only when it  improves this scene. Apply the correction before

• 00:42:42 the final masked composite, so the selected asset  changes while the original background remains the

• 00:42:48 destination. Keep the opacity mask aligned with  the corrected colour image at the same dimensions.

• 00:43:02 Let us enlarge the edge again. In straight  alpha, colour is stored independently of

• 00:43:07 opacity. In premultiplied alpha, colour has  already been multiplied by opacity. Mixing

• 00:43:13 those interpretations can create a dark or  bright fringe. Use the alpha interpretation

• 00:43:19 expected by the receiving application, then  inspect the saved result over light and dark

• 00:43:25 backgrounds. If the edge changes brightness  unexpectedly, check that interpretation before

• 00:43:30 painting away useful transparent detail. I  am reopening the final PNG and comparing the

• 00:43:42 background outside the accepted region. Keep the  original destination, the transparent source and

• 00:43:47 the composite together. That gives you an editable  asset instead of only a flattened final picture.

• 00:44:07 Our last example goes beyond cutting out  an object. We will ask Qwen-Image-Layered

• 00:44:13 to decompose this product scene into an ordered  set of images. The foreground lantern overlaps

• 00:44:18 a travel case and the tabletop behind it. Layered  uses its own model, text encoder and RGBA decoder.

• 00:44:26 The Qwen 2.1 files from the previous example are a  different component set. I am opening the official

• 00:44:32 Layered workflow and its download information.  Download the diffusion model into diffusion

• 00:44:38 models, the text encoder into text encoders, and  the decoder into the VAE folder. Keep the complete

• 00:44:44 filenames visible, then refresh the application  and select those exact files in the loaders.

• 00:45:13 We are using the mixed precision model listed  with this template. Its files have different

• 00:45:19 memory and storage requirements from the earlier  editing models. Check the download size and free

• 00:45:25 storage before starting. I am loading our product  scene into the workflow. We will keep its original

• 00:45:33 pixels as a comparison. The model creates  a reconstructed layered version, so we will

• 00:45:38 inspect both the reconstruction and each layer  it produces. The working resolution sets the

• 00:45:45 image size used for decomposition. The layer count  controls how many separate layers we request. Use

• 00:45:51 a small, understandable scene first, then inspect  whether its objects are separated usefully.

• 00:45:58 The template keeps the generated full-image  reconstruction separately from the extracted

• 00:46:03 layer batch. We will preserve that order when  decoding and saving. A different batch position

• 00:46:09 can mean a different object or background layer.  I am starting the decomposition run now. Once it

• 00:46:16 finishes, we will inspect the full reconstruction,  preview the alpha of each layer, and recombine

• 00:46:22 them before moving the foreground object to  another position. Here is the reconstructed

• 00:46:38 image beside the original product scene. Compare  the lantern shape, travel case and wood grain.

• 00:46:44 Keep any changed details visible as we decide how  useful this decomposition is for the planned edit.

• 00:46:52 Now I am opening the layers in their saved order.  Look at the colour and alpha together. An isolated

• 00:46:58 layer can contain transparent areas around its  object and newly generated content where another

• 00:47:04 object previously covered it. The background  layer comes first in the composite. Place the

• 00:47:10 next layer over it using that layer's opacity,  then continue through the stack. Changing this

• 00:47:16 order can place a background element in front of  the lantern. I am reconnecting the layers in that

• 00:47:30 order and viewing the composite. Compare it with  the model's reconstruction, then with the original

• 00:47:36 source. Those 2 comparisons answer different  practical questions about the layer output.

• 00:47:50 Matching the reconstruction checks our layer  order and compositing path. Comparing against

• 00:47:55 the source shows what the model changed  while decomposing the scene. Inspect the

• 00:48:01 table texture and object edges before  making another edit. Keep each saved

• 00:48:06 layer as an RGBA PNG. A flattened image loses the  independent opacity and placement controls. The

• 00:48:13 numbered filenames in the lesson folder preserve  the order used by this recomposition graph. Now

• 00:48:29 I am changing the horizontal position of the  foreground lantern layer. The background and

• 00:48:34 travel case remain in their own branches. We can  move this 1 object without regenerating the entire

• 00:48:41 composite again. Watch the area where the lantern  used to be. Some of that background was hidden in

• 00:48:52 the original photograph. The layered model had to  infer content there, so inspect the newly revealed

• 00:48:58 wood and travel case carefully. Segmentation  selects pixels that were visible in the source.

• 00:49:05 Layer decomposition can also generate the  content needed behind an occluding object.

• 00:49:10 This is why moving a layer is a stronger test than  viewing a stationary cutout. Look at the lantern's

• 00:49:17 contact with the table after the move. A shadow or  reflection can remain in another layer or at the

• 00:49:23 old position. Decide which layers need to move  together so the edited scene remains coherent.

• 00:49:29 I am comparing the original placement and moved  version side by side. Inspect the old position,

• 00:49:36 the new position and the overall balance.  Keep the separate layers so you can revise

• 00:49:41 the placement without starting the decomposition  again. The final composite is saved under a new

• 00:49:48 name. I am reopening it and then reopening  the layered workflow. The saved inputs,

• 00:49:53 ordered layers and placement values remain  available for another edit after this session.

• 00:50:21 We have repaired the watercolor mark,  extended a scene, selected objects with words,

• 00:50:27 and edited a local face region. The same  spatial question runs through all of them:

• 00:50:32 which pixels should this operation affect? Use  a painted or segmented mask when you need an

• 00:50:38 explicit region. Give a local edit enough  surrounding context, inspect its boundary,

• 00:50:43 and use the original as the final composite  destination when outside pixels must stay

• 00:50:49 exact. Use a transparent asset for independent  placement, and use layer decomposition when you

• 00:50:56 need separately editable parts of a scene. Inspect  the revealed background after moving an object,

• 00:51:02 because that is where inferred content  becomes visible. The downloadable files

• 00:51:07 include the source images, masks, workflows and  saved results. Keep the model links and folder

• 00:51:14 instructions with them. You can follow these  graphs with an image and edit of your own.

• 00:51:24 In Lecture 6 we will add structural control,  using maps that describe the shapes and

• 00:51:29 composition we want the model to follow.  Try 1 local repair with today's workflow,

• 00:51:34 and inspect both the patch and the untouched  surroundings. Thank you for watching. If this

• 00:51:40 lecture helped you, please like the video  and subscribe to SECourses. You can use

• 00:51:46 the chapters in the description to return  directly to the technique you need next.
